Preset Adjustment of the Picture Level Control Knobs - CONTROL
PRESET ADJ Menu
110 MANUAL (PRESET/xxCH): Adjust values by turning the PHASE, BRIGHT,
CHROMA, and/or CONTRAST knobs.
PHASE: xxxx
CHROMA: xxxx
BRIGHT: xxxx
CONTRAST: xxxx
120 AUTO (PRESET/xxCH): Select the color bar signal to be used for automatic adjustment
=:> Adjustment Is carried out.
FULL FIELD CB 100: 100% full-field color bar
FULL FIELD CB 75: 75% full-field color bar
SMPTE CB: SMPTE standard color bar
EIA CB: EIA standard color bar
130 COPY (PRESET/xxCH): Select the source to be copied from.
OTHER VALUE ... : Copy data from another channel or from PRESET setting. =:> 131
OTHER MONITOR ... :
Copy data from another monitor.=!> 133
MEMORY CARD ... : Copy data from a memory card. =!> 136
131 OTHER VALUE (PRESET/xxCH): Choose either PRESET or CH SET.
=:> Copy Is carried out •
PRESET: Copy common data.
CH SET: Copy data set for another channel. Input the number of the channel from which
the data will be copied.
133 OTHER MONITOR (PRESET/xxCH): Input the address of the monitor from
which the data will be copied.
=:> 134
j MONITOR ADDRESS: Input the address.
134 OTHER MONITOR (PRESET/xxCH): Choose either PRESET or CH SET.
=:> Copy Is carried out,
PRESET: Copy common data.
CH SET: Copy data set for another channel. Input the number of the channel from
which the data will
be copied.
136 MEMORY CARD (PRESET/xxCH): Select the file name. =!> 137
[ FILE NAME: Select the file name.
137 FILE NAME (PRESET/xxCH): Choose either PRESET or CH SET.
=:> Copy Is carried out.
PRESET: Copy common data.
CH SET: Copy data set for another channel. Input the number of the channel from
which
the data will be copied.
Adjusting the Color Temperature - COLOR TEMP
ADJ Menu
The color temperature is adjusted with the COLOR
TEMP ADJ menu. The color temperature can be set
either commonly to all channels or individually for
each channel.
The adjusted value can then be used as an original
value.
Color temperature adjustment can
be made in the
following four ways:
(I) Knob adjustment
Adjust the color temperature with the bias and gain
knobs.
(2) Automatic adjustment using a probe
Bias and gain can be adjusted automatically by
connecting a color analyzer such as the Minolta CA-
100.
(3) Copying other data
Copying data from other channels, common data, other
BVM-series monitors that have been connected via the
serial remote connector, or from data stored in monitor
memory cards
(4) Restoring factory settings
>i~rfftl,, •• 1111~~ilit;~i
1
il/:: ,&j}1.::t;
This section explains the setting lists displayed in the
menu.
The lists are numbered and shown with indentations to
indicate the hierarchy in the menu.
If a setting in each list leads to another list or a
monitor operation, the list number or the operation is
indicated after the
=:> mark. (Settings without the =:>
mark end in a single !isl.)
Select COLOR TEMP ADJ from the main menu list.
CONTROL PRESET ADJ ...
St:TUP ...
MEMORY CARD ...
COPY ...
STATUS ...
MAINTENANCE ...
KEY PROTECT OFF
Menu list
l
200 COLOR TEMP ADJ menu: Select STD, COL I, COL2, or CH SET. =!> 201
STD: Use common data (factory setting: D65).
COLI: Use common data (factory setting: D65 ).
COL2: Use common data (factory setting: D93).
CH SET: Use data for each individual channel (factory setting: D65). Use the numeric keypad to select the
desired channel.
