5 Pull out rail A from rail 8.
1111!1
Talce care not to get your
fingers caught between the
rails.
6 Attach rail A to the monitor.
7 Atlach the front bracket and
rear bracket to rail B.
8 Attach rails B to the rack.
Rack
®
I
®
@ 8cf8ws ®PSW4x20
,_l__
JR~r
:e> I
~--r ! Tlg .. en the .... , '
@i Long
1
! screwlettk>ose J
! i \, .
f i
l =J
9 Insert rails A attached 10 the
monitor into rails B.
mm
Push the monitor all the way
into the rack, without releasing
your grip until you hear an
audible click as the plate
springs of rails A are fixed in
place. Unless they are fixed in
place, there is a danger that the
monitor might fall out of the
rack.
1 Dusing screws appropriate for
the rack's screw holes, secure
the monitor to the rack.
Appropriate
screws
Removing the monitor from the rack
,Ai?
r
Hold the plate spring
with your finger and pul
out.
Rack
·---··---·----
To Next Page
