Sony CDP-XA555ES - Front Panel Mechanical Details; Front Panel Component Breakdown

49
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
(2) FRONT PANEL SECTION
#3
#3
supplied with RV 870
not
supplied
#3
#3
not
supplied
supplied with
J461, RV350
not
supplied
#7
53
73
51
54
55
73
73
56
60
59
59
59
62
59
58
57
63
59
59
59
64
59
67
71
52
66
65
68
69
70
72
59
A
B
A
B
52
51 4-221-254-01 PANEL, FRONT (GOLD)
51 4-221-254-11 PANEL, FRONT (BLACK)
52 4-220-319-01 BUTTON (MODE) (GOLD)
52 4-220-319-11 BUTTON (MODE) (BLACK)
53 4-942-568-41 EMBLEM (NO.5), SONY
54 4-221-262-01 KNOB (VOL) (GOLD)
54 4-221-262-11 KNOB (VOL) (BLACK)
55 3-354-981-01 SPRING (SUS), RING
56 4-221-255-01 BASE (LM), PANEL (GOLD)
56 4-221-255-11 BASE (LM), PANEL (BLACK)
57 4-923-520-81 KNOB, POWER (GOLD)
57 4-923-520-91 KNOB, POWER (BLACK)
58 1-674-836-11 SW BOARD
59 4-951-620-01 SCREW (2.6X8), +BVTP
60 1-674-835-11 KEY-L BOARD
62 1-674-837-11 VR BOARD
63 4-221-260-01 PACKING
64 4-221-261-01 RETAINER (PACKING)
65 A-4724-829-A KEY-R BOARD, COMPLETE
* 66 3-362-478-11 HOLDER (T), LED
67 4-221-258-01 BUTTON (FR) (GOLD)
67 4-221-258-11 BUTTON (FR) (BLACK)
68 X-4951-807-1 BUTTON (PLAY) ASSY (BLACK)
68 X-4951-808-1 BUTTON (PLAY) ASSY (GOLD)
69 4-221-256-01 BASE (R), PANEL (GOLD)
69 4-221-256-11 BASE (R), PANEL (BLACK)
70 4-221-263-01 KNOB (AMS) (GOLD)
70 4-221-263-11 KNOB (AMS) (BLACK)
71 4-220-317-01 BUTTON (FILTER)
72 4-220-711-01 INDICATOR (FILTER)
* 73 4-615-354-01 SPACER
