Sony CDP-XA555ES - Disassembly Instructions; Loading Panel Removal Steps

8
LOADING PANEL
Note: Follow the disassembly procedure in the numerical order given.
SECTION 3
DISASSEMBLY
INOUT
2 tray
– BOTTOM VIEW –
1 Open the tray turning
the tapering screw driver
to the arrow direction.
5 loading panel
4 two screws
(KTP3
× 8)
6 connector (CN292)
3 two hexagon hole
bolt (LID)
