Location of controls
Wired remote (RM-X87)
Refer to the pages for details.
1 AMS (Automatic Music Sensor/manual
search) control 6, 7
2 REP (repeat play) indication
3 SHUF (shuffle play) indication
4 DISC NAME (disc number/disc name)
indication
The indicated disc number matches the
disc number in the disc magazine.
5 TRACK NAME (track number/track
name) indication
6 MIN (minute) indication
7 SEC (second) indication
8 DISC (disc select) buttons 6, 7, 9
9 u (play/pause) button 6
If pressed during CD playback, the CD
will pause. If pressed again, CD playback
will continue.
0 Infrared receptor for the wireless
remote
qa OFF button 6
qs Play/pause indication
Turns around during CD playback and
flashes when the pause button is pressed.
qd DSPL-SCRL (indication change/name
scroll) button
qf SHUF/REP (shuffle play/repeat play/
control mode set) button 6, 7, 9
