Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
SERVO
C15 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C16 1-163-989-11 CERAMIC CHIP 0.033uF 10% 25V
C17 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C18 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C19 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C20 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C21 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V
C22 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C23 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C24 1-163-125-00 CERAMIC CHIP 220PF 5% 50V
C25 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C26 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C27 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C28 1-163-023-00 CERAMIC CHIP 0.015uF 5% 50V
C29 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C30 1-126-603-11 ELECT CHIP 4.7uF 20% 35V
C31 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C32 1-163-023-00 CERAMIC CHIP 0.015uF 5% 50V
C33 1-124-779-00 ELECT CHIP 10uF 20% 16V
C34 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C35 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C36 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C37 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C38 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C39 1-126-204-11 ELECT CHIP 47uF 20% 16V
C40 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
< CONNECTOR >
CN1 1-764-616-12 HOUSING, CONNECTOR (PC BOARD) 30P
CN2 1-565-728-11 CONNECTOR, FPC 17P
CN3 1-770-347-21 CONNECTOR, FPC 6P
< IC >
IC1 8-752-372-94 IC CXD2507AQ
IC2 8-752-074-34 IC CXA1782BQ
IC3 8-759-354-16 IC BA6796FP-T1
< JUMPER RESISTOR >
JR1 1-216-296-00 SHORT 0
JR2 1-216-296-00 SHORT 0
JR3 1-216-296-00 SHORT 0
JR4 1-216-296-00 SHORT 0
JR5 1-216-296-00 SHORT 0
JR6 1-216-296-00 SHORT 0
JR7 1-216-296-00 SHORT 0
JR8 1-216-296-00 SHORT 0
JR9 1-216-296-00 SHORT 0
JR10 1-216-296-00 SHORT 0
JR11 1-216-296-00 SHORT 0
JR12 1-216-296-00 SHORT 0
JR13 1-216-296-00 SHORT 0
JR14 1-216-296-00 SHORT 0
JR15 1-216-296-00 SHORT 0
JR16 1-216-296-00 SHORT 0
JR17 1-216-296-00 SHORT 0
JR18 1-216-296-00 SHORT 0
JR19 1-216-296-00 SHORT 0
JR20 1-216-296-00 SHORT 0
JR21 1-216-296-00 SHORT 0
JR22 1-216-296-00 SHORT 0
JR23 1-216-296-00 SHORT 0
JR24 1-216-296-00 SHORT 0
JR25 1-216-296-00 SHORT 0
JR26 1-216-296-00 SHORT 0
JR27 1-216-296-00 SHORT 0
JR28 1-216-296-00 SHORT 0
JR29 1-216-296-00 SHORT 0
JR30 1-216-296-00 SHORT 0
JR31 1-216-296-00 SHORT 0
JR32 1-216-296-00 SHORT 0
JR33 1-216-296-00 SHORT 0
JR34 1-216-296-00 SHORT 0
JR35 1-216-296-00 SHORT 0
JR36 1-216-296-00 SHORT 0
JR37 1-216-296-00 SHORT 0
JR38 1-216-296-00 SHORT 0
JR39 1-216-296-00 SHORT 0
JR40 1-216-296-00 SHORT 0
JR41 1-216-296-00 SHORT 0
JR42 1-216-296-00 SHORT 0
JR43 1-216-296-00 SHORT 0
JR44 1-216-296-00 SHORT 0
JR45 1-216-296-00 SHORT 0
JR46 1-216-296-00 SHORT 0
< COIL >
L1 1-412-058-11 INDUCTOR CHIP 10uH
L2 1-412-058-11 INDUCTOR CHIP 10uH
L3 1-412-058-11 INDUCTOR CHIP 10uH
< TRANSISTOR >
Q1 8-729-904-60 TRANSISTOR DTB113ZK
Q2 8-729-904-86 TRANSISTOR 2SB1197K-Q
< RESISTOR >
R1 1-216-073-00 METAL CHIP 10K 5% 1/10W
R2 1-216-097-00 RES,CHIP 100K 5% 1/10W
R3 1-216-121-00 RES,CHIP 1M 5% 1/10W
R4 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R5 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R6 1-216-073-00 METAL CHIP 10K 5% 1/10W
R7 1-216-009-00 METAL CHIP 22 5% 1/10W
R8 1-216-119-00 METAL CHIP 820K 5% 1/10W
R9 1-216-119-00 METAL CHIP 820K 5% 1/10W
R10 1-216-073-00 METAL CHIP 10K 5% 1/10W
