– 66 –
SUB
The components identified by
mark ! or dotted line with mark.
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R11 1-216-073-00 METAL CHIP 10K 5% 1/10W
R14 1-216-085-00 METAL CHIP 33K 5% 1/10W
R15 1-216-085-00 METAL CHIP 33K 5% 1/10W
R16 1-216-077-00 METAL CHIP 15K 5% 1/10W
R17 1-216-081-00 METAL CHIP 22K 5% 1/10W
R19 1-216-079-00 METAL CHIP 18K 5% 1/10W
R20 1-216-105-00 RES,CHIP 220K 5% 1/10W
R21 1-216-105-00 RES,CHIP 220K 5% 1/10W
R22 1-216-085-00 METAL CHIP 33K 5% 1/10W
R23 1-216-121-00 RES,CHIP 1M 5% 1/10W
R24 1-216-073-00 METAL CHIP 10K 5% 1/10W
R27 1-216-295-00 SHORT 0
R28 1-216-101-00 METAL CHIP 150K 5% 1/10W
R29 1-216-097-00 RES,CHIP 100K 5% 1/10W
R30 1-216-097-00 RES,CHIP 100K 5% 1/10W
R31 1-216-081-00 METAL CHIP 22K 5% 1/10W
R32 1-216-109-00 METAL CHIP 330K 5% 1/10W
R33 1-216-105-00 RES,CHIP 220K 5% 1/10W
R34 1-216-009-00 METAL CHIP 22 5% 1/10W
R35 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R36 1-216-097-00 RES,CHIP 100K 5% 1/10W
R37 1-216-117-00 METAL CHIP 680K 5% 1/10W
R38 1-216-109-00 METAL CHIP 330K 5% 1/10W
R39 1-216-101-00 METAL CHIP 150K 5% 1/10W
R40 1-216-114-00 RES,CHIP 510K 5% 1/10W
R41 1-216-093-00 METAL CHIP 68K 5% 1/10W
R42 1-216-103-00 METAL CHIP 180K 5% 1/10W
R43 1-216-097-00 RES,CHIP 100K 5% 1/10W
R44 1-216-085-00 METAL CHIP 33K 5% 1/10W
R45 1-216-081-00 METAL CHIP 22K 5% 1/10W
R46 1-216-097-00 RES,CHIP 100K 5% 1/10W
R47 1-216-105-00 RES,CHIP 220K 5% 1/10W
R48 1-216-073-00 METAL CHIP 10K 5% 1/10W
R49 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R50 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R51 1-216-295-00 SHORT 0
< VARIABLE RESISTOR >
RV1 1-238-091-11 RES, ADJ, CERMET 22K
RV4 1-238-091-11 RES, ADJ, CERMET 22K
*************************************************************
* 1-659-834-11 SUB BOARD
**********
< CONNECTOR >
CN1 1-770-347-21 CONNECTOR, FPC 6P
*************************************************************
SERVO
MISCELLANEOUS
***************
11 1-776-207-82 CORD (WITH CONNECTOR) (POWER)
207 1-659-880-11 MOTOR FLEXIBLE BOARD
! 210 8-820-010-06 PICK-UP, OPTICAL KSS-521A/K1RP
212 1-659-881-11 PICK-UP FLEXIBLE BOARD
F901 1-532-877-11 FUSE (BLADE TYPE) (AUTO FUSE) 10A
M901 X-3371-664-2 MOTOR ASSY (SPINDLE)
M902 A-3291-674-A MOTOR ASSY, SLED
M903 A-3291-676-A MOTOR SUB ASSY, LOADING
*************************************************************
ACCESSORIES & PACKING MATERIALS
********************************
3-861-717-11 MANUAL, INSTRUCTION (ENGLISH,SPANISH,
CHINESE) (E)
3-861-717-31 MANUAL, INSTRUCTION (ENGLISH)
(US,Canadian)
3-861-717-41 MANUAL, INSTRUCTION (FRENCH) (Canadian)
3-861-718-11 MANUAL, INSTRUCTION, INSTALL (ENGLISH,
SPANISH,CHINESE) (E)
3-861-718-31 MANUAL, INSTRUCTION, INSTALL (ENGLISH,
FRENCH) (US,Canadian)
X-3374-810-1 CASE ASSY
*************************************************************
**************
HARDWARE LIST
**************
#1 7-685-792-09 SCREW +PTT 2.6X6 (S)
#2 7-685-793-09 SCREW +PTT 2.6X8 (S)
#3 7-621-772-10 SCREW +B 2X4
#4 7-685-106-19 SCREW +P 2X10 TYPE 2 NON-SLIT
#5 7-627-850-28 SCREW, PRECISION +P 1.4X3
#6 7-627-000-00 SCREW, PRECISION +P 1.7X2.2 TYPE 3
#7 7-628-253-00 SCREW +PS 2X4
#8 7-627-553-37 SCREW, PRECISION +P 2X3 TYPE 3
#9 7-627-553-17 SCREW, PRECISION +P 2X2 TYPE 3
#10 7-685-794-09 SCREW +PTT 2.6X10 (S)
#11 7-685-547-14 SCREW +BTP 3X10 TYPE 2 N-S
*************************************************************
