15
CDX-GT40W/GT400/GT450/GT450S
2-8. SL MOTOR ASSY (M902)
2-7. OPTICAL PICK-UP
1
tension coil spring (CHKG
)
2
chucking arm sub assy
3
screw
4
rack (SL)
5
claw
6
main shaft
7
optical pick-up
1
screw
(+P 1.4
×
1.8
)
2
SL motor assy (M902)
