CDX-GT49UM/GT490U/GT490US/GT494U
9
Note:
Follow the disassembly procedure in the numerical order shown below
.
3-1.
SUB P
ANEL
ASSY
3-2.
CD MECHANISM BLOCK
2
two claws
3
two
claws
4
sub panel assy
1
two
screws
(+PTT
2.6
u
6)
4
CN701
3
1
screw
(+PTT
2.6
u
6)
2
screw
(+PTT
2.6
u
6)
6
two
screws
(+PTT
2.6
u
4)
7
bracket (CD)
8
CD mechanism block
5
CN501 (3P)
8
10
Table of Contents
Default Chapter
3
Table of Contents
3
1 Service Note
4
2 General
5
Connections
5
3 Disassembly
8
Sub Panel Assy
9
CD Mechanism Block
9
Main Board
10
Servo Board
10
Chassis (T) Sub Assy
11
Roller Arm Assy
11
Chassis (OP) Assy
12
Chucking Arm Sub Assy
12
Sled Motor Assy
13
3-10. Optical Pick-Up Section
14
3-11. Optical Pick-Up
14
4 Diagrams
15
Block Diagram -Main Section
15
Block Diagram -Display Section
16
Printed Wiring Board -Main Section
18
Schematic Diagram -Main Section (1/3)
19
Schematic Diagram -Main Section (2/3)
20
Schematic Diagram -Main Section (3/3)
21
Printed Wiring Boards -Key Section
22
Schematic Diagram -Key Section
23
5 Exploded Views
29
Main Section
29
Front Panel Section
30
CD Mechanism Section (MG-101Y-188//Q)
31
6 Electrical Parts List
32
Revision History
40
