CDX-MP40
SECTION 5
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• RESISTORS
All resistors are in ohms.
METAL:Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F:nonflammable
•Abbreviation
CND: Canadian model
• Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
• SEMICONDUCTORS
In each case, u : µ, for example:
uA.. : µA.. uPA.. : µPA..
uPB.. : µPB.. uPC.. : µPC.. uPD.. : µPD..
• CAPACITORS
uF : µF
• COILS
uH : µH
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0 sont critiques pour
la sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
When indicating parts by reference
number, please include the board.
DISPLAY
A-3274-253-A DISC IN SW BOARD, COMPLETE
**************************
*************************************************************
DISPLAY BOARD (US,CND)
**************
1-694-989-11 CONDUCTIVE BOARD, CONNECTION (US,CND)
< CAPACITOR >
C951 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
(US,CND)
C952 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
(US,CND)
C953 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
(US,CND)
C954 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
(US,CND)
C955 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(US,CND)
C956 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(US,CND)
< CONNECTOR >
CN901 1-817-158-11 PLUG, CONNECTOR 14P (US,CND)
< DIODE >
D901 8-719-083-66 DIODE UDZS-TE-17-18B (US,CND)
D902 8-719-978-33 DIODE DTZ-TT11-6.8B (US,CND)
D903 8-719-978-33 DIODE DTZ-TT11-6.8B (US,CND)
D904 8-719-978-33 DIODE DTZ-TT11-6.8B (US,CND)
D905 8-719-988-61 DIODE 1SS355TE-17 (US,CND)
D907 8-719-978-33 DIODE DTZ-TT11-6.8B (US,CND)
D951 8-719-069-54 DIODE UDZS-TE-17-5.1B (US,CND)
< IC >
IC901 8-759-826-21 IC LC75874W (US,CND)
IC951 8-749-017-35 IC KSM-401N (US,CND)
< LIQUID CRYSTAL DISPLAY >
LCD901 1-805-084-11 DISPLAY PANEL, LIQUID CRYSTAL (US,CND)
< DIODE >
LED901 8-719-053-09 LED SML-310VT-T86 (SOURCE) (US,CND)
LED902 8-719-053-09 LED SML-310VT-T86 (EQ3) (US,CND)
LED903 8-719-053-09 LED SML-310VT-T86 (EQ3) (US,CND)
LED904 8-719-053-09 LED SML-310VT-T86 (DSO) (US,CND)
LED905 8-719-053-09 LED SML-310VT-T86 (DSO) (US,CND)
LED906 8-719-053-09 LED SML-310VT-T86 (SEEK) (US,CND)
LED910 6-500-459-01 LED NSCW505T-ARS (LCD BACK LIGHT)
(US,CND)
LED911 6-500-459-01 LED NSCW505T-ARS (LCD BACK LIGHT)
(US,CND)
< SWITCH >
LSW901 1-771-476-11 SWITCH, KEYBOARD (WITH LED) (OFF)
(US,CND)
LSW902 1-771-476-11 SWITCH, KEYBOARD (WITH LED) (MODE)
(US,CND)
LSW903 1-771-476-11 SWITCH, KEYBOARD (WITH LED) (SEL)
(US,CND)
LSW904 1-771-476-11 SWITCH, KEYBOARD (WITH LED) (VOLUME +)
(US,CND)
LSW905 1-771-476-11 SWITCH, KEYBOARD (WITH LED) (VOLUME –)
(US,CND)
LSW906 1-771-476-11 SWITCH, KEYBOARD (WITH LED) (ATT)
(US,CND)
LSW907 1-771-883-31 SWITCH, TACTILE (WITH LED) (SENS)
(US,CND)
LSW908 1-771-883-31 SWITCH, TACTILE (WITH LED) (1/DISC –)
(US,CND)
LSW909 1-771-883-31 SWITCH, TACTILE (WITH LED) (2/DISC +)
(US,CND)
LSW910 1-771-883-31 SWITCH, TACTILE (WITH LED) (3/REP)
(US,CND)
LSW911 1-771-476-11 SWITCH, KEYBOARD (WITH LED)
(+ > M SEEK) (US,CND)
LSW912 1-771-476-11 SWITCH, KEYBOARD (WITH LED)
(SEEK m . –) (US,CND)
LSW913 1-771-476-11 SWITCH, KEYBOARD (WITH LED) (DSPL)
(US,CND)
LSW914 1-771-883-31 SWITCH, TACTILE (WITH LED) (BTM)
(US,CND)
LSW915 1-771-883-31 SWITCH, TACTILE (WITH LED) (6) (US,CND)
LSW916 1-771-883-31 SWITCH, TACTILE (WITH LED) (5) (US,CND)
LSW917 1-771-883-31 SWITCH, TACTILE (WITH LED) (4/SHUF)
(US,CND)
< RESISTOR >
R901 1-216-819-11 METAL CHIP 680 5% 1/10W
(US,CND)
DISC IN SW
