Sony CDX-MP40 - Page 46

46
CDX-MP40
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R931 1-216-041-00 METAL CHIP 470 5% 1/10W
(AEP,UK)
R934 1-216-017-11 RES-CHIP 47 5% 1/10W
(AEP,UK)
R935 1-216-025-11 RES-CHIP 100 5% 1/10W
(AEP,UK)
R936 1-216-021-00 METAL CHIP 68 5% 1/10W
(AEP,UK)
R941 1-216-025-11 RES-CHIP 100 5% 1/10W
(AEP,UK)
R942 1-216-021-00 METAL CHIP 68 5% 1/10W
(AEP,UK)
R946 1-216-025-11 RES-CHIP 100 5% 1/10W
(AEP,UK)
R947 1-216-021-00 METAL CHIP 68 5% 1/10W
(AEP,UK)
R950 1-216-025-11 RES-CHIP 100 5% 1/10W
(AEP,UK)
R951 1-216-021-00 METAL CHIP 68 5% 1/10W
(AEP,UK)
R960 1-216-025-11 RES-CHIP 100 5% 1/10W
(AEP,UK)
R961 1-216-025-11 RES-CHIP 100 5% 1/10W
(AEP,UK)
R962 1-216-029-00 METAL CHIP 150 5% 1/10W
(AEP,UK)
R966 1-216-025-11 RES-CHIP 100 5% 1/10W
(AEP,UK)
R967 1-216-037-00 METAL CHIP 330 5% 1/10W
(AEP,UK)
R970 1-216-864-11 METAL CHIP 0 5% 1/10W
(AEP,UK)
R971 1-216-821-11 METAL CHIP 1K 5% 1/10W
(AEP,UK)
R972 1-216-809-11 METAL CHIP 100 5% 1/10W
(AEP,UK)
R975 1-216-817-11 METAL CHIP 470 5% 1/10W
(AEP,UK)
R976 1-216-817-11 METAL CHIP 470 5% 1/10W
(AEP,UK)
R977 1-216-817-11 METAL CHIP 470 5% 1/10W
(AEP,UK)
R978 1-216-817-11 METAL CHIP 470 5% 1/10W
(AEP,UK)
R979 1-216-817-11 METAL CHIP 470 5% 1/10W
(AEP,UK)
R980 1-216-817-11 METAL CHIP 470 5% 1/10W
(AEP,UK)
R981 1-216-811-11 METAL CHIP 150 5% 1/10W
(AEP,UK)
R982 1-216-811-11 METAL CHIP 150 5% 1/10W
(AEP,UK)
R983 1-216-811-11 METAL CHIP 150 5% 1/10W
(AEP,UK)
R985 1-216-864-11 METAL CHIP 0 5% 1/10W
(AEP,UK)
R986 1-216-821-11 METAL CHIP 1K 5% 1/10W
(AEP,UK)
R987 1-216-821-11 METAL CHIP 1K 5% 1/10W
(AEP,UK)
R988 1-216-821-11 METAL CHIP 1K 5% 1/10W
(AEP,UK)
R989 1-216-840-11 METAL CHIP 39K 5% 1/10W
(AEP,UK)
R990 1-216-857-11 METAL CHIP 1M 5% 1/10W
(AEP,UK)
< SWITCH >
S902 1-771-884-31 SWITCH, TACTILE (WITH LED) (SOURCE)
(AEP,UK)
S903 1-771-884-31 SWITCH, TACTILE (WITH LED) (DSO)
(AEP,UK)
S911 1-771-884-31 SWITCH, TACTILE (WITH LED) (EQ3)
(AEP,UK)
*************************************************************
A-3274-254-A LIMIT SW BOARD, COMPLETE
*************************
< CONNECTOR >
CN13 1-816-275-21 CONNECTOR, FFC/FPC 6P
*************************************************************
1-685-337-11 LOAD SW BOARD
***************
*************************************************************
A-3274-739-A MAIN BOARD, COMPLETE (US,CND)
A-3274-742-A MAIN BOARD, COMPLETE (AEP,UK)
*********************
* 3-019-565-01 BRACKET (IC)
3-041-261-11 BRACKET (TR)
7-685-134-19 SCREW +P 2.6X8 TYPE2 NON-SLIT
7-685-793-09 SCREW +PTT 2.6X8 (S)
7-685-795-09 SCREW +PTT 2.6X12 (S)
< CAPACITOR >
C101 1-136-154-00 FILM 0.012uF 5% 50V
C106 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C109 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C201 1-136-154-00 FILM 0.012uF 5% 50V
C202 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C203 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C204 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C205 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C206 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C207 1-164-160-11 CERAMIC CHIP 20PF 5% 50V
C208 1-126-160-11 ELECT 1uF 20% 50V
C209 1-126-160-11 ELECT 1uF 20% 50V
C210 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C211 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C212 1-126-160-11 ELECT 1uF 20% 50V
C213 1-126-160-11 ELECT 1uF 20% 50V
C215 1-104-946-11 ELECT 10uF 20% 35V
C401 1-128-428-11 ELECT 10uF 20% 35V
C402 1-128-428-11 ELECT 10uF 20% 35V
C403 1-128-428-11 ELECT 10uF 20% 35V
C404 1-128-428-11 ELECT 10uF 20% 35V
C405 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C406 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C407 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C408 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
KEY
LIMIT SW MAINLOAD SW
