50
CDX-MP40
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
< THERMISTOR (POSITIVE) >
TH900 1-801-792-21 THERMISTOR, POSITIVE
TH901 1-810-940-11 THERMISTOR, POSITIVE
< TUNER >
TUX501 A-3220-887-A TUNER UNIT (TUX-030)
< VIBRATOR >
X601 1-760-556-31 VIBRATOR, CRYSTAL (4.332MHz) (AEP,UK)
X801 1-795-165-11 VIBRATOR, CERAMIC (18.43MHz)
X802 1-567-098-41 VIBRATOR, CRYSTAL (32.768kHz)
*************************************************************
RELAY BOARD
************
1-792-173-11 CABLE, FLAT (FFC) 12P (CNP903)
< CAPACITOR >
C973 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C974 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CNP902 1-817-159-11 SOCKET, CONNECTOR 14P
< DIODE >
D901 8-719-978-33 DIODE DTZ-TT11-6.8B
D902 8-719-978-33 DIODE DTZ-TT11-6.8B
D903 8-719-978-33 DIODE DTZ-TT11-6.8B
D904 8-719-978-33 DIODE DTZ-TT11-6.8B
D905 8-719-978-33 DIODE DTZ-TT11-6.8B
D906 8-719-978-33 DIODE DTZ-TT11-6.8B
D907 8-719-978-33 DIODE DTZ-TT11-6.8B
LED930 8-719-082-38 LED CL-270SR-C-TS (CD WINDOW)
LED931 8-719-053-09 LED SML-310VT-T86 (Z)
< RESISTOR >
R930 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R931 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R932 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
< SWITCH >
S931 1-771-884-31 SWITCH, TACTILE (WITH LED) (Z)
*************************************************************
A-3274-698-A SERVO BOARD, COMPLETE
**********************
< CAPACITOR >
C1 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C3 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C4 1-104-609-11 ELECT CHIP 100uF 20% 4V
C5 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C6 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C8 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C9 1-162-924-11 CERAMIC CHIP 56PF 5% 50V
C10 1-162-924-11 CERAMIC CHIP 56PF 5% 50V
C11 1-162-909-11 CERAMIC CHIP 4PF 0.25PF 50V
C13 1-162-916-11 CERAMIC CHIP 12PF 5% 50V
C14 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C15 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C16 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C17 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C18 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C19 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C20 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C21 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C22 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C23 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C24 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C25 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C27 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C29 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C30 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C34 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C35 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C36 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C38 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C39 1-126-391-11 ELECT CHIP 47uF 20% 6.3V
C40 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C41 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C43 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C44 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C45 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C51 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C53 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C54 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C55 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C56 1-128-934-11 CERAMIC CHIP 0.33uF 20% 10V
C57 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C58 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C59 1-104-609-11 ELECT CHIP 100uF 20% 4V
C60 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C61 1-126-391-11 ELECT CHIP 47uF 20% 6.3V
C62 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C63 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C65 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C67 1-104-851-11 TANTAL. CHIP 10uF 20% 10V
C68 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C69 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C70 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C75 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C77 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C78 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C79 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C81 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C102 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C111 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C112 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C113 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C114 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN1 1-815-352-11 CONNECTOR, BOARD TO BOARD 30P
CN2 1-794-153-21 CONNECTOR, FPC (ZIF) 16P
CN3 1-816-275-21 CONNECTOR, FFC/FPC 6P
RELAY SERVO
