– 67 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R66 1-247-831-91 CARBON 1K 5% 1/4W
R67 1-249-429-11 CARBON 10K 5% 1/4W
R68 1-249-417-11 CARBON 1K 5% 1/4W
R69 1-249-417-11 CARBON 1K 5% 1/4W
R101 1-249-431-11 CARBON 15K 5% 1/4W
R102 1-249-404-00 CARBON 82 5% 1/4W
R103 1-249-441-11 CARBON 100K 5% 1/4W
R104 1-247-843-11 CARBON 3.3K 5% 1/4W
R105 1-247-831-91 CARBON 1K 5% 1/4W
R106 1-247-831-91 CARBON 1K 5% 1/4W
R107 1-249-429-11 CARBON 10K 5% 1/4W
R108 1-247-863-11 CARBON 22K 5% 1/4W
R109 1-249-418-11 CARBON 1.2K 5% 1/4W
R110 1-249-425-11 CARBON 4.7K 5% 1/4W
R121 1-249-425-11 CARBON 4.7K 5% 1/4W
R141 1-249-428-11 CARBON 8.2K 5% 1/4W
R145 1-249-437-11 CARBON 47K 5% 1/4W
R151 1-247-887-00 CARBON 220K 5% 1/4W
R201 1-249-431-11 CARBON 15K 5% 1/4W
R202 1-249-404-00 CARBON 82 5% 1/4W
R203 1-249-441-11 CARBON 100K 5% 1/4W
R204 1-247-843-11 CARBON 3.3K 5% 1/4W
R205 1-247-831-91 CARBON 1K 5% 1/4W
R206 1-247-831-91 CARBON 1K 5% 1/4W
R207 1-249-429-11 CARBON 10K 5% 1/4W
R208 1-247-863-11 CARBON 22K 5% 1/4W
R209 1-249-418-11 CARBON 1.2K 5% 1/4W
R210 1-249-425-11 CARBON 4.7K 5% 1/4W
R221 1-249-425-11 CARBON 4.7K 5% 1/4W
R241 1-249-428-11 CARBON 8.2K 5% 1/4W
R245 1-249-437-11 CARBON 47K 5% 1/4W
R251 1-247-887-00 CARBON 220K 5% 1/4W
R301 1-247-903-00 CARBON 1M 5% 1/4W
R302 1-247-831-91 CARBON 1K 5% 1/4W
R303 1-249-429-11 CARBON 10K 5% 1/4W
R304 1-249-429-11 CARBON 10K 5% 1/4W
R305 1-247-831-91 CARBON 1K 5% 1/4W
R321 1-249-399-11 CARBON 33 5% 1/4W
R322 1-247-831-91 CARBON 1K 5% 1/4W
R323 1-247-831-91 CARBON 1K 5% 1/4W
R324 1-247-831-91 CARBON 1K 5% 1/4W
R325 1-249-413-11 CARBON 470 5% 1/4W
R327 1-247-895-00 CARBON 470K 5% 1/4W
R328 1-249-418-11 CARBON 1.2K 5% 1/4W
R329 1-249-411-11 CARBON 330 5% 1/4W
R330 1-247-903-00 CARBON 1M 5% 1/4W
R331 1-249-426-11 CARBON 5.6K 5% 1/4W
R332 1-249-431-11 CARBON 15K 5% 1/4W
R361 1-249-437-11 CARBON 47K 5% 1/4W
R362 1-247-831-91 CARBON 1K 5% 1/4W
R364 1-249-437-11 CARBON 47K 5% 1/4W
R365 1-247-831-91 CARBON 1K 5% 1/4W
R366 1-249-429-11 CARBON 10K 5% 1/4W
R367 1-249-413-11 CARBON 470 5% 1/4W
R369 1-249-429-11 CARBON 10K 5% 1/4W
R372 1-247-863-11 CARBON 22K 5% 1/4W
R373 1-247-863-11 CARBON 22K 5% 1/4W
R374 1-247-863-11 CARBON 22K 5% 1/4W
R375 1-249-429-11 CARBON 10K 5% 1/4W
R376 1-249-429-11 CARBON 10K 5% 1/4W
R377 1-249-429-11 CARBON 10K 5% 1/4W
R381 1-249-441-11 CARBON 100K 5% 1/4W
R382 1-247-831-91 CARBON 1K 5% 1/4W
R383 1-249-441-11 CARBON 100K 5% 1/4W
R384 1-247-831-91 CARBON 1K 5% 1/4W
R385 1-249-441-11 CARBON 100K 5% 1/4W
R386 1-247-831-91 CARBON 1K 5% 1/4W
R387 1-249-417-11 CARBON 1K 5% 1/4W
R388 1-249-425-11 CARBON 4.7K 5% 1/4W
R389 1-249-426-11 CARBON 5.6K 5% 1/4W
< TRANSFORMER >
T1 1-433-741-11 TRANSFORMER, IF
< VIBRATOR >
X1 1-760-130-11 VIBRATOR, CRYSTAL (75kHz)
**************************************************************
* A-3322-179-A POWER BOARD, COMPLETE
***********************
(not including IC303)
1-533-233-31 HOLDER, FUSE
7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S
< CAPACITOR >
C141 1-126-960-11 ELECT 1uF 20% 50V
C142 1-162-302-11 CERAMIC 0.0022uF 20% 16V
C143 1-126-926-11 ELECT 1000uF 10V
C144 1-162-306-11 CERAMIC 0.01uF 20% 16V
C241 1-126-960-11 ELECT 1uF 20% 50V
C242 1-162-302-11 CERAMIC 0.0022uF 20% 16V
C243 1-126-926-11 ELECT 1000uF 10V
C244 1-162-306-11 CERAMIC 0.01uF 20% 16V
C341 1-126-963-11 ELECT 4.7uF 20% 50V
C342 1-104-664-11 ELECT 47uF 20% 10V
C343 1-162-294-31 CERAMIC 0.001uF 10% 50V
C344 1-162-294-31 CERAMIC 0.001uF 10% 50V
C345 1-162-294-31 CERAMIC 0.001uF 10% 50V
C346 1-162-294-31 CERAMIC 0.001uF 10% 50V
C351 1-162-306-11 CERAMIC 0.01uF 20% 16V
C352 1-162-306-11 CERAMIC 0.01uF 20% 16V
C353 1-104-665-11 ELECT 100uF 20% 10V
C354 1-162-306-11 CERAMIC 0.01uF 20% 16V
C355 1-162-306-11 CERAMIC 0.01uF 20% 16V
C356 1-126-934-11 ELECT 220uF 20% 10V
C357 1-128-547-11 ELECT 6800uF 20% 16V
C901 1-161-494-00 CERAMIC 0.022uF 25V
C902 1-161-494-00 CERAMIC 0.022uF 25V
C903 1-161-494-00 CERAMIC 0.022uF 25V
C904 1-161-494-00 CERAMIC 0.022uF 25V
C905 1-162-306-11 CERAMIC 0.01uF 20% 16V
C906 1-162-306-11 CERAMIC 0.01uF 20% 16V
C907 1-126-964-11 ELECT 10uF 20% 50V
C908 1-162-306-11 CERAMIC 0.01uF 20% 16V
MAIN POWER
