– 68 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
< CONNECTOR >
* CNP351 1-785-657-11 PIN, CONNECTOR (PC BOARD) 5P
< DIODE >
D351 8-719-109-97 DIODE RD6.8ES-B2
D352 8-719-109-89 DIODE RD5.6ESB2
D353 8-719-991-33 DIODE 1SS133T-77
D901 8-719-200-02 DIODE 10E2
D902 8-719-200-02 DIODE 10E2
D903 8-719-200-02 DIODE 10E2
D904 8-719-200-02 DIODE 10E2
D905 8-719-200-02 DIODE 10E2
D906 8-719-981-95 DIODE MTZJ-2.7B
D907 8-719-049-26 DIODE RB721Q
D908 8-719-991-33 DIODE 1SS133T-77
D909 8-719-991-33 DIODE 1SS133T-77
D910 8-719-991-33 DIODE 1SS133T-77
D911 8-719-991-33 DIODE 1SS133T-77
D912 8-719-991-33 DIODE 1SS133T-77
< FUSE >
0F901 1-532-464-31 FUSE (T2.5AL/250V)
< IC >
IC303 8-759-543-56 IC LA4601N
(not included in POWER board, complete)
< JACK >
J301 1-566-891-11 JACK (i)
0J901 1-526-838-11 INLET, AC 2P (- AC IN)
< TRANSISTOR >
Q341 8-729-036-62 TRANSISTOR KRC106M-AT
Q351 8-729-801-84 TRANSISTOR 2SB1013-4
Q352 8-729-036-62 TRANSISTOR KRC106M-AT
Q353 8-729-021-82 TRANSISTOR 2SD2396K
Q354 8-729-036-86 TRANSISTOR KTC3203Y-AT
< RESISTOR >
R142 1-249-413-11 CARBON 470 5% 1/4W
R143 1-247-831-91 CARBON 1K 5% 1/4W
R144 1-247-807-31 CARBON 100 5% 1/4W
R242 1-249-413-11 CARBON 470 5% 1/4W
R243 1-247-831-91 CARBON 1K 5% 1/4W
R244 1-247-807-31 CARBON 100 5% 1/4W
R341 1-247-807-31 CARBON 100 5% 1/4W
R342 1-247-831-91 CARBON 1K 5% 1/4W
R351 1-249-437-11 CARBON 47K 5% 1/4W
R352 1-247-831-91 CARBON 1K 5% 1/4W
R353 1-247-815-91 CARBON 220 5% 1/4W
R354 1-249-429-11 CARBON 10K 5% 1/4W
R355 1-247-815-91 CARBON 220 5% 1/4W
R356 1-247-807-31 CARBON 100 5% 1/4W
R901 1-247-807-31 CARBON 100 5% 1/4W
R902 1-247-807-31 CARBON 100 5% 1/4W
0R903 1-249-387-11 CARBON 3.3 5% 1/4W F
R904 1-249-401-11 CARBON 47 5% 1/4W
< TRANSFORMER >
0T901 1-431-231-11 TRANSFORMER, POWER
**************************************************************
* 1-675-540-11 REC SW BOARD
**************
< CAPACITOR >
C311 1-162-292-31 CERAMIC 680PF 10% 50V
C312 1-104-664-11 ELECT 47uF 20% 10V
C313 1-137-431-11 MYLAR 560PF 5% 50V
C314 1-162-284-31 CERAMIC 150PF 10% 50V
C315 1-162-285-31 CERAMIC 180PF 10% 50V
C316 1-127-888-21 CERAMIC 0.1uF 10% 50V
< CONNECTOR >
* CNP301 1-785-656-11 PIN, CONNECTOR (PC BOARD) 4P
< TRANSISTOR >
Q311 8-729-281-53 TRANSISTOR 2SC1815-GR
Q312 8-729-281-53 TRANSISTOR 2SC1815-GR
Q313 8-729-281-53 TRANSISTOR 2SC1815-GR
< RESISTOR >
R311 1-249-408-11 CARBON 180 5% 1/4W
R312 1-249-435-11 CARBON 33K 5% 1/4W
R313 1-249-393-11 CARBON 10 5% 1/4W
R314 1-249-441-11 CARBON 100K 5% 1/4W
R315 1-249-425-11 CARBON 4.7K 5% 1/4W
R316 1-249-425-11 CARBON 4.7K 5% 1/4W
< SWITCH >
S301 1-762-565-11 SWITCH, SLIDE (REC/PB)
< TRANSFORMER >
T311 1-416-041-11 TRANSFORMER, BIAS OSCILLATION
**************************************************************
MISCELLANEOUS
**************
55 1-790-242-11 WIRE (FLAT TYPE) (16 CORE)
59 1-452-899-11 MAGNET
170 8-719-038-29 DIODE SLP-181B-51
0301 8-848-483-06 OPTICAL PICK-UP KSS-213C
306 X-2626-202-1 CHASSIS ASSY (MB) (RP), MOTOR (SPINDLE)
(including M701)
ANT1 1-501-820-11 ANTENNA, TELESCOPIC (FM)
HE301 1-543-876-11 HEAD (ERASE)
HRP301 1-500-454-11 HEAD, MAGNETIC (RECORD/PLAYBACK)
M301 A-3320-446-A MOTOR ASSY (WITH PULLY) (CAPSTAN/REEL)
M702 X-2625-769-1 GEAR ASSY (MB), MOTOR (SLED)
S303 1-762-679-11 SWITCH, LEAF (MOTOR ON/OFF)
S304 1-771-059-11 SWITCH, LEAF (TAPE PLAY)
S701 1-692-960-11 SWITCH, PUSH (1 KEY)
(CD DOOR OPEN/CLOSE)
SP101 1-529-478-11 SPEAKER (L ch)
POWER REC SW
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
