– 8 –
FRONT CABINET SECTION
MAIN BOARD
2
two screws
(BTP3
×
12)
A
1
three connectors
(CNP302, 303, 309)
2
two screws
(BTP3
×
12)
3
Remove the front
cabinet section in
the arrow
A
direction.
rear cabinet
section
2
two screws
(BVTP3
×
10)
1
two connectors
(CNP304, 305)
1
three connectors
(CNP306, 311, 312)
2
two screws
(BVTP3
×
10)
3
MAIN board
1
connector
(CNP1)
