Sony CFD-G500 - Page 35

35
CFD-G500/G500L
Pin No. Pin Name I/O Description
72 VDD – Power supply
73 VSS – Ground
74 X1 I Main system clock oscillator input (4.19MHz)
75 X2 O Main system clock oscillator output (4.19MHz)
76 RST I System reset signal input
77 CD O CD function signal output “L”: active
78 LED CONT O LED control signal output (not used)
79 W-LED1 O Woofer1 LED control signal output
80 W-LED2 O Woofer2 LED control signal output
