Sony CFD-G500 - Page 45

45
CFD-G500/G500L
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C338 1-126-964-11 ELECT 10uF 20% 50V
C339 1-104-658-91 ELECT 100uF 20% 10V
C340 1-104-658-91 ELECT 100uF 20% 10V
C341 1-104-662-91 ELECT 22uF 20% 25V
C342 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C346 1-126-942-11 ELECT 1000uF 25V
C348 1-128-548-11 ELECT 4700uF 20% 25V
C349 1-104-666-11 ELECT 220uF 20% 25V
C350 1-162-995-11 CERAMIC CHIP 0.022uF 50V
C351 1-104-658-91 ELECT 100uF 20% 10V
C352 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C353 1-104-658-91 ELECT 100uF 20% 10V
C354 1-104-658-91 ELECT 100uF 20% 10V
C355 1-104-658-91 ELECT 100uF 20% 10V
C356 1-104-658-91 ELECT 100uF 20% 10V
C357 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C358 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C359 1-104-662-91 ELECT 22uF 20% 25V
C360 1-126-962-11 ELECT 3.3uF 20% 50V
C361 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C366 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C371 1-104-658-91 ELECT 100uF 20% 10V
C801 1-126-960-11 ELECT 1uF 20% 50V
C802 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C803 1-126-923-91 ELECT 220uF 20% 10V
C810 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C812 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C814 1-104-662-91 ELECT 22uF 20% 25V
C816 1-126-923-91 ELECT 220uF 20% 10V
C817 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C818 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C824 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C825 1-162-915-11 CERAMIC CHIP 10P 5% 50V
C826 1-162-915-11 CERAMIC CHIP 10P 5% 50V
C827 1-162-915-11 CERAMIC CHIP 10P 5% 50V
C828 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C829 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C830 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C831 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C832 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C833 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C834 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C835 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C838 1-126-959-11 ELECT 0.47uF 20% 50V
C839 1-126-959-11 ELECT 0.47uF 20% 50V
C844 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
(AEP,UK,CET)
C845 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
(AEP,UK,CET)
C846 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C951 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C953 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C954 1-126-923-91 ELECT 220uF 20% 10V
C955 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C957 1-126-923-91 ELECT 220uF 20% 10V
C958 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C959 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C960 1-126-923-91 ELECT 220uF 20% 10V
C961 1-126-923-91 ELECT 220uF 20% 10V
C972 1-164-156-11 CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
* CNP301 1-815-553-11 PIN, CONNECTOR (PWB) 5P
CNP303 1-815-554-11 PIN, CONNECTOR (PWB) 6P
CNP801 1-784-749-11 CONNECTOR, FFC 27P
CNP802 1-784-775-11 CONNECTOR, FFC 14P
CNP804 1-815-443-21 PIN, CONNECTOR (PWB) 2P
CNP805 1-770-519-31 CONNECTOR, FFC/FPC 11P(US,CND,E,SP,AUS)
CNP805 1-784-735-11 CONNECTOR, FFC 13P (AEP,UK,CET)
CNP806 1-815-443-11 PIN, CONNECTOR (PWB) 2P
< DIODE >
D320 8-719-988-61 DIODE 1SS355TE-17
D321 8-719-988-61 DIODE 1SS355TE-17
D322 8-719-988-61 DIODE 1SS355TE-17
D323 8-719-988-61 DIODE 1SS355TE-17
D324 8-719-988-61 DIODE 1SS355TE-17
D325 8-719-988-61 DIODE 1SS355TE-17
D326 8-719-988-61 DIODE 1SS355TE-17
D351 8-719-988-61 DIODE 1SS355TE-17
D352 8-719-988-61 DIODE 1SS355TE-17
D806 8-719-988-61 DIODE 1SS355TE-17
D807 8-719-988-61 DIODE 1SS355TE-17
D808 8-719-069-55 DIODE UDZSTE-175.6B
D951 8-719-988-61 DIODE 1SS355TE-17 (EXCEPT US, E)
D952 8-719-988-61 DIODE 1SS355TE-17 (EXCEPT US, E)
D953 8-719-988-61 DIODE 1SS355TE-17 (EXCEPT US, E)
D954 8-719-069-61 DIODE UDZSTE-1710B
D955 8-719-069-57 DIODE UDZSTE-176.8B
D956 8-719-083-58 DIODE UDZSTE-173.9B
D957 8-719-988-61 DIODE 1SS355TE-17 (EXCEPT US, E)
< IC >
IC321 6-701-824-11 IC BD3870FS-E2
IC801 6-803-965-01 IC uPD789478GC-A24-8BT
IC802 6-703-285-01 IC S-812C33AUA-C2NT2G
IC803 6-700-336-01 IC CAT24WC02JI-1.8-TE13
IC805 6-705-413-01 IC BD4826G-TR
< COIL >
L802 1-410-334-31 INDUCTOR 100uH
< TRANSISTOR >
Q171 8-729-901-81 TRANSISTOR 2SC2412K-T-146-R
Q271 8-729-901-81 TRANSISTOR 2SC2412K-T-146-R
Q321 8-729-901-81 TRANSISTOR 2SC2412K-T-146-R
Q322 8-729-901-81 TRANSISTOR 2SC2412K-T-146-R
Q323 8-729-028-99 TRANSISTOR DTC114YUA-T106
Q351 8-729-036-89 TRANSISTOR KTC3198GR-AT
Q352 8-729-028-90 TRANSISTOR DTA143Z
Q354 8-729-036-86 TRANSISTOR KTC3203Y-AT
Q809 8-729-028-76 TRANSISTOR DTA114YUA-T106
Q810 8-729-037-03 TRANSISTOR KTA1266GR-AT
Q951 8-729-029-04 TRANSISTOR DTC123JUA-T106
(EXCEPT US, E)
MAIN
