Sony CFD-G500 - Page 47

47
CFD-G500/G500L
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R863 1-216-864-11 SHORT CHIP 0 (AEP,UK,CET)
R864 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R865 1-216-821-11 METAL CHIP 1K 5% 1/10W
R866 1-216-821-11 METAL CHIP 1K 5% 1/10W
R867 1-216-864-11 SHORT CHIP 0
R868 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R869 1-216-837-11 METAL CHIP 22K 5% 1/10W
R870 1-216-864-11 SHORT CHIP 0
R871 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R872 1-216-797-11 METAL CHIP 10 5% 1/10W
(US,CND,E)
R872 1-216-864-11 SHORT CHIP 0 (EXCEPT US,CND,E)
R873 1-216-853-11 METAL CHIP 470K 5% 1/10W
R874 1-216-821-11 METAL CHIP 1K 5% 1/10W
R875 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R876 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R877 1-216-864-11 SHORT CHIP 0
R878 1-216-809-11 METAL CHIP 100 5% 1/10W
R879 1-216-809-11 METAL CHIP 100 5% 1/10W
R880 1-216-864-11 SHORT CHIP 0
R881 1-216-821-11 METAL CHIP 1K 5% 1/10W
R882 1-216-833-11 METAL CHIP 10K 5% 1/10W
R883 1-216-833-11 METAL CHIP 10K 5% 1/10W
R885 1-216-841-11 METAL CHIP 47K 5% 1/10W
R886 1-216-821-11 METAL CHIP 1K 5% 1/10W
R887 1-216-821-11 METAL CHIP 1K 5% 1/10W
R888 1-216-864-11 SHORT CHIP 0
R889 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R890 1-216-864-11 SHORT CHIP 0
R896 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R898 1-216-853-11 METAL CHIP 470K 5% 1/10W
R899 1-216-841-11 METAL CHIP 47K 5% 1/10W
R941 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R942 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R943 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R944 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R945 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R946 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R947 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R948 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R949 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R950 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R951 1-216-845-11 METAL CHIP 100K 5% 1/10W
R952 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R953 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R955 1-216-809-11 METAL CHIP 100 5% 1/10W
R957 1-216-809-11 METAL CHIP 100 5% 1/10W
R958 1-216-821-11 METAL CHIP 1K 5% 1/10W
R960 1-216-809-11 METAL CHIP 100 5% 1/10W
R961 1-216-821-11 METAL CHIP 1K 5% 1/10W
(EXCEPT US,E)
R964 1-216-809-11 METAL CHIP 100 5% 1/10W
R965 1-216-817-11 METAL CHIP 470 5% 1/10W
R8001 1-216-833-11 METAL CHIP 10K 5% 1/10W
R8002 1-216-833-11 METAL CHIP 10K 5% 1/10W
R8003 1-216-833-11 METAL CHIP 10K 5% 1/10W
R8004 1-216-833-11 METAL CHIP 10K 5% 1/10W
R8005 1-216-833-11 METAL CHIP 10K 5% 1/10W
R8006 1-216-833-11 METAL CHIP 10K 5% 1/10W
R8007 1-216-833-11 METAL CHIP 10K 5% 1/10W
R8008 1-216-833-11 METAL CHIP 10K 5% 1/10W
R8009 1-216-833-11 METAL CHIP 10K 5% 1/10W
R8010 1-216-833-11 METAL CHIP 10K 5% 1/10W
R8011 1-216-833-11 METAL CHIP 10K 5% 1/10W
R8012 1-216-833-11 METAL CHIP 10K 5% 1/10W
R8013 1-216-833-11 METAL CHIP 10K 5% 1/10W
R8014 1-216-833-11 METAL CHIP 10K 5% 1/10W
R8015 1-216-833-11 METAL CHIP 10K 5% 1/10W
R8016 1-216-833-11 METAL CHIP 10K 5% 1/10W
R8017 1-216-833-11 METAL CHIP 10K 5% 1/10W
R8018 1-216-833-11 METAL CHIP 10K 5% 1/10W
R8019 1-216-833-11 METAL CHIP 10K 5% 1/10W
R8020 1-216-833-11 METAL CHIP 10K 5% 1/10W
R8021 1-216-833-11 METAL CHIP 10K 5% 1/10W
R8022 1-216-833-11 METAL CHIP 10K 5% 1/10W
< VIBRATOR >
X801 1-795-054-21 VIBRATOR, CERAMIC 4.19MHz
X802 1-795-915-11 VIBRATOR, CRYSTAL 32.768KHz
************************************************************
* 1-860-920-11 POWER BOARD
*************
< CAPACITOR
C901 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
(AEP,UK,SP,AUS,CET)
C901 1-163-037-11 CERAMIC CHIP 0.022uF 10% 50V
(US,CND,E)
C902 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
(AEP,UK,SP,AUS,CET)
C902 1-163-037-11 CERAMIC CHIP 0.022uF 10% 50V
(US,CND,E)
C903 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
(AEP,UK,SP,AUS,CET)
C903 1-163-037-11 CERAMIC CHIP 0.022uF 10% 50V
(US,CND,E)
C904 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
(AEP,UK,SP,AUS,CET)
C904 1-163-037-11 CERAMIC CHIP 0.022uF 10% 50V
(US,CND,E)
C909 1-126-943-11 ELECT 2200uF 20% 25V
< JACK >
0CNJ901 1-526-818-11 INLET, AC (E)
0CNJ901 1-526-838-11 INLET, AC 2P (AEP,UK,SP,AUS,CET)
0CNJ901 1-540-009-11 INLET, AC (US,CND)
< CONNECTOR >
* CNP902 1-815-552-11 PIN, CONNECTOR (PWB) 4P
< DIODE >
D901 8-719-046-47 DIODE 1N5401TM
D902 8-719-046-47 DIODE 1N5401TM
MAIN POWER
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
