Sony CFD-S01 - Page 32

32
CFD-S01
IC703 BA5826FP-E2 (MAIN Board (1/4))
1
2
3
4
5
6
7
8
9
10
11
12
13
14
28
27
26
24
23
22
21
20
19
18
17
16
15
25
LEVEL
SHIFT
LEVEL
SHIFT
THERMAL
SHUT-DOWN
MONITOR
LEVEL
SHIFT
LEVEL
SHIFT
D.BUFF
D.BUFF
D.BUFF
GND
SLIN
(SLIN)
VREF
VCC
VCC
(FIN)
FIN
F–
F+
SL+
SL–
NC
OPIN
SP–
REG–B
SP+
SPIN
RST
REGO
MUTE
GND
TIN
(TIN)
T–
T+
GND
OPOUT
D.BUFF
D.BUFF
D.BUFF
D.BUFF
D.BUFF
REGULATOR
DRIVER
MUTE
VCC
VCC
IC303 TA8227P (MAIN Board (4/4))
6
L-IN L-NF PREGND L-BS L-OUT VCC2
R-IN
R-NF
RIPPLE
R-BS
R-OUT
VCC1
5 4 3 2 1
7 8 9 10 11 12
