51
CFD-S01
< TRANSISTOR >
Q301 8-729-901-81 TRANSISTOR 2SC2412K-T-146-R
< RESISTOR >
R101 1-216-837-11 METAL CHIP 22K 5% 1/10W
R102 1-216-805-11 METAL CHIP 47 5% 1/10W
R103 1-216-845-11 METAL CHIP 100K 5% 1/10W
R104 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R105 1-216-837-11 METAL CHIP 22K 5% 1/10W
R106 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R107 1-216-841-11 METAL CHIP 47K 5% 1/10W
R108 1-216-801-11 METAL CHIP 22 5% 1/10W
R109 1-216-849-11 METAL CHIP 220K 5% 1/10W
R110 1-216-809-11 METAL CHIP 100 5% 1/10W
R111 1-216-833-11 METAL CHIP 10K 5% 1/10W
R112 1-216-821-11 METAL CHIP 1K 5% 1/10W
R201 1-216-837-11 METAL CHIP 22K 5% 1/10W
R202 1-216-805-11 METAL CHIP 47 5% 1/10W
R203 1-216-845-11 METAL CHIP 100K 5% 1/10W
R204 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R205 1-216-837-11 METAL CHIP 22K 5% 1/10W
R206 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R207 1-216-841-11 METAL CHIP 47K 5% 1/10W
R208 1-216-801-11 METAL CHIP 22 5% 1/10W
R209 1-216-849-11 METAL CHIP 220K 5% 1/10W
R210 1-216-809-11 METAL CHIP 100 5% 1/10W
R211 1-216-833-11 METAL CHIP 10K 5% 1/10W
R212 1-216-821-11 METAL CHIP 1K 5% 1/10W
R301 1-216-857-11 METAL CHIP 1M 5% 1/10W
R302 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R303 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R304 1-216-821-11 METAL CHIP 1K 5% 1/10W
R305 1-216-817-11 METAL CHIP 470 5% 1/10W
R306 1-216-833-11 METAL CHIP 10K 5% 1/10W
R307 1-216-797-11 METAL CHIP 10 5% 1/10W
R308 1-216-837-11 METAL CHIP 22K 5% 1/10W
R309 1-216-805-11 METAL CHIP 47 5% 1/10W
R312 1-216-837-11 METAL CHIP 22K 5% 1/10W
R314 1-216-817-11 METAL CHIP 470 5% 1/10W
R315 1-216-817-11 METAL CHIP 470 5% 1/10W
< SWITCH >
S301 1-786-126-11 SWITCH, SLIDE (REC/PB)
< TRANSFORMER >
T301 1-443-758-11 TRANSFORMER, BIAS OSCILLATION
*************************************************************
Ref. No. Part No. Description Remark
TC
MISCELLANEOUS
***************
56 1-797-376-11 DECK, MECHANICAL
152 1-452-899-11 MAGNET
204 1-831-623-11 CABLE, FLEXIBLE FLAT (16 CORE)
206 1-831-614-11 CABLE, FLEXIBLE FLAT (6 CORE)
0 217 8-820-126-01 OPTICAL PICK-UP (KSM-213CDP/C2NP)
255 X-2162-709-2 CHASSIS ASSY (CDP), MOTOR (SPINDLE)
(including M701)
0 256 8-848-483-12 OPTICAL PICK-UP (KSS-213C/C2RP1)
ANT2 1-754-376-11 ANTENNA, TELESCOPIC (FM)
0 F902 1-533-468-12 FUSE, GLASS TUBE (DIA. 5) (2A/250V)
M702 X-2625-769-1 GEAR ASSY (MB) (RP), MOTOR (SLED)
S801 1-692-960-21 SWITCH, PUSH (1 KEY)
(Z PUSH OPEN/CLOSE)
SP101 1-826-280-11 SPEAKER (7.7cm) (L-CH)
SP201 1-826-280-11 SPEAKER (7.7cm) (R-CH)
0 T901 1-443-861-11 TRANSFORMER, POWER
(EXCEPT CND,E92,MX,TW)
0 T901 1-443-871-11 TRANSFORMER, POWER (CND,E92,MX,TW)
*************************************************************
ACCESSORIES
************
0 1-590-342-12 CORD, POWER (E92,MX)
0 1-769-412-22 CORD, POWER (AEP,UK,CET,SP,E41,IT,TH)
0 1-770-019-61 ADAPTOR, CONVERSION PLUG (UK)
0 1-776-985-12 CORD, POWER (KR)
0 1-782-126-11 CORD, POWER (CND)
0 1-783-952-21 CORD, POWER (AR)
0 1-827-945-12 CORD, POWER (AUS)
0 1-827-946-21 CORD, POWER (UK)
0 1-829-433-11 CORD, POWER (TW)
2-655-834-13 MANUAL, INSTRUCTION (ENGLISH)
(CND,E92,TW)
2-655-834-21 MANUAL, INSTRUCTION (FRENCH) (CND)
2-655-834-32 MANUAL, INSTRUCTION (ENGLISH)
(AEP,UK,AUS,KR,SP,AR,TH)
2-655-834-41 MANUAL, INSTRUCTION (FRENCH,GERMAN)
(AEP,SP)
2-655-834-51 MANUAL, INSTRUCTION
(DUTCH,PORTUGUESE) (AEP)
2-655-834-61 MANUAL, INSTRUCTION (ITALIAN) (IT)
2-655-834-71 MANUAL, INSTRUCTION (FINNISH,SWEDISH)
(CET)
2-655-834-81 MANUAL, INSTRUCTION (POLISH) (CET)
2-655-834-91 MANUAL, INSTRUCTION (CZECH,HUNGARIAN)
(CET)
2-655-835-11 MANUAL, INSTRUCTION
(SLOVAKIAN,RUSSIAN) (CET)
2-655-835-21 MANUAL, INSTRUCTION (KOREAN) (KR)
2-655-835-41 MANUAL, INSTRUCTION (SPANISH) (E92,MX)
2-655-835-51 MANUAL, INSTRUCTION (SPANISH)
(AEP,E41,AR)
2-655-835-61 MANUAL, INSTRUCTION
(TRADITIONAL CHINESE) (TW)
2-655-835-71 MANUAL, INSTRUCTION (UKRAINIAN) (CET)
Ref. No. Part No. Description Remark
Ver. 1.3
