38
CFD-S03CP/S03CPL
50 ISS2 O ISS control signal output
51 MD2 I Operation mode setting pin
52 MD1 I Operation mode setting pin
53 MD0 I Operation mode setting pin
54 RESET I System reset signal input
55 CD-ON O Audio CD mode control signal output
56 TU-ON — Not used (Open)
57 TAPE O Audio tape mode control signal output
58 VLCD — Not used (Open)
59 to 62 COM4 to 4 O LCD drive common signal output
63 SEG29 O LCD drive segment signal output
64 SEG28 O LCD drive segment signal output
65 VCC — Power supply (+3.3 V)
66 VSS — Ground
67 to 89 SEG27 to 5 O LCD drive segment signal output
90 VCC — Power supply (+3.3 V)
91 VSS — Ground
92 X1 O Main system oscillation output (4.19 MHz)
93 X0 I Main system oscillation input (4.19 MHz)
94 to 97 SEG4 to 1 O LCD drive segment signal output
99 to 100 NC — Not used (Open)
Pin No. Pin Name I/O Pin Description
