– 56 –
SECTION 8
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
BATTERY
* 1-676-627-11 BATTERY BOARD
**************
3-028-154-01 TERMINAL (–), BATTERY
*************************************************************
* A-3322-451-A CD BOARD, COMPLETE
*******************
3-048-457-01 TAPE (CD SHIELD PLATE)
< CAPACITOR >
C701 1-104-665-11 ELECT 100uF 20% 10V
C702 1-115-185-11 CERAMIC CHIP 0.033uF 10% 50V
C703 1-163-113-00 CERAMIC CHIP 68PF 5% 50V
C704 1-104-664-11 ELECT 47uF 20% 10V
C706 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C707 1-104-665-11 ELECT 100uF 20% 10V
C708 1-104-665-11 ELECT 100uF 20% 10V
C709 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C710 1-104-665-11 ELECT 100uF 20% 10V
C711 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C712 1-163-019-00 CERAMIC CHIP 0.0068uF 10% 50V
C713 1-164-343-11 CERAMIC CHIP 0.056uF 10% 25V
C714 1-104-329-11 CERAMIC CHIP 0.1uF 10% 50V
C715 1-163-189-00 CERAMIC CHIP 220PF 10% 50V
C716 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C717 1-104-665-11 ELECT 100uF 20% 10V
C718 1-163-059-11 CERAMIC CHIP 0.01uF 10% 50V
C720 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C721 1-163-059-11 CERAMIC CHIP 0.01uF 10% 50V
C722 1-126-959-11 ELECT 0.47uF 20% 50V
C723 1-163-189-00 CERAMIC CHIP 220PF 5% 50V
C726 1-163-011-11 CERAMIC CHIP 0.0015uF 10% 50V
C727 1-104-760-11 CERAMIC CHIP 0.047uF 10% 50V
C728 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C729 1-104-665-11 ELECT 100uF 20% 10V
C730 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C731 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C732 1-163-059-11 CERAMIC CHIP 0.01uF 10% 50V
C733 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C734 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C735 1-126-963-11 ELECT 4.7uF 20% 50V
C736 1-126-963-11 ELECT 4.7uF 20% 50V
C737 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C738 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C739 1-163-007-11 CERAMIC CHIP 680PF 10% 50V
C740 1-163-255-11 CERAMIC CHIP 150PF 5% 50V
C743 1-163-255-11 CERAMIC CHIP 150PF 5% 50V
C744 1-163-007-11 CERAMIC CHIP 680PF 10% 50V
C745 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C746 1-126-925-11 ELECT 470uF 20% 10V
C747 1-163-059-11 CERAMIC CHIP 0.01uF 10% 50V
C757 1-163-181-00 CERAMIC CHIP 100PF 5% 50V
C758 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C759 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C760 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C761 1-104-665-11 ELECT 100uF 20% 10V
C762 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C763 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C764 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C765 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C766 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C768 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C770 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C773 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C780 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C781 1-104-665-11 ELECT 100uF 20% 10V
< CONNECTOR >
CNP701 1-779-466-11 CONNECTOR, FFC (LIF (NON-ZIF)) 16P
CNP702 1-784-739-11 CONNECTOR, FFC 17P
< IC >
IC701 8-752-083-15 IC CXA2550M
IC702 8-752-386-85 IC CXD2587Q
IC703 8-759-549-28 IC BA5974FP-E2
< JUMPER RESISTOR >
JC701 1-216-296-00 SHORT 0
JC702 1-216-296-00 SHORT 0
JC703 1-216-296-00 SHORT 0
JC704 1-216-296-00 SHORT 0
JC705 1-216-296-00 SHORT 0
JC706 1-216-296-00 SHORT 0
JC707 1-216-296-00 SHORT 0
JC708 1-216-296-00 SHORT 0
JC709 1-216-296-00 SHORT 0
JC710 1-216-296-00 SHORT 0
JC711 1-216-296-00 SHORT 0
CD
• Abbreviation
IT : Italian model
CET : East European & CIS model
NOTE:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• RESISTORS
All resistors are in ohms.
METAL:Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F:nonflammable
• Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
• SEMICONDUCTORS
In each case, u : µ, for example:
uA.. : µA.. uPA.. : µPA..
uPB.. : µPB.. uPC.. : µPC.. uPD.. : µPD..
• CAPACITORS
uF : µF
• COILS
uH : µH
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
