Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
JC712 1-216-296-00 SHORT 0
JC713 1-216-295-00 SHORT 0
JC714 1-216-296-00 SHORT 0
JC715 1-216-296-00 SHORT 0
JC716 1-216-296-00 SHORT 0
JC717 1-216-296-00 SHORT 0
JC718 1-216-296-00 SHORT 0
JC719 1-216-296-00 SHORT 0
JC720 1-216-296-00 SHORT 0
JC721 1-216-296-00 SHORT 0
JC722 1-216-296-00 SHORT 0
JC723 1-216-296-00 SHORT 0
JC724 1-216-296-00 SHORT 0
JC725 1-216-296-00 SHORT 0
JC726 1-216-296-00 SHORT 0
JC727 1-216-296-00 SHORT 0
JC728 1-216-296-00 SHORT 0
JC729 1-216-296-00 SHORT 0
JC730 1-216-296-00 SHORT 0
JC731 1-216-296-00 SHORT 0
JC732 1-216-296-00 SHORT 0
JC733 1-216-296-00 SHORT 0
JC734 1-216-296-00 SHORT 0
JC735 1-216-296-00 SHORT 0
JC736 1-216-296-00 SHORT 0
JC737 1-216-296-00 SHORT 0
JC738 1-216-296-00 SHORT 0
JC739 1-216-296-00 SHORT 0
JC740 1-216-296-00 SHORT 0
JC741 1-216-295-00 SHORT 0
JC742 1-216-296-00 SHORT 0
JC743 1-216-296-00 SHORT 0
JC744 1-216-296-00 SHORT 0
JC745 1-216-296-00 SHORT 0
JC746 1-216-296-00 SHORT 0
JC747 1-216-296-00 SHORT 0
JC748 1-216-296-00 SHORT 0
JC750 1-216-295-00 SHORT 0
JC751 1-216-296-00 SHORT 0
JC752 1-216-296-00 SHORT 0
JC754 1-216-295-00 SHORT 0
JC755 1-216-296-00 SHORT 0
JC756 1-216-296-00 SHORT 0
JC757 1-216-296-00 SHORT 0
JC758 1-216-296-00 SHORT 0
JC759 1-216-296-00 SHORT 0
JC760 1-216-296-00 SHORT 0
JC761 1-216-296-00 SHORT 0
JC762 1-216-296-00 SHORT 0
JC763 1-216-296-00 SHORT 0
JC764 1-216-295-00 SHORT 0
JC765 1-216-295-00 SHORT 0
JC766 1-216-296-00 SHORT 0
JC767 1-216-296-00 SHORT 0
JC768 1-216-296-00 SHORT 0
JC769 1-216-296-00 SHORT 0
JC770 1-216-296-00 SHORT 0
JC771 1-216-296-00 SHORT 0
JC772 1-216-295-00 SHORT 0
JC773 1-216-296-00 SHORT 0
JC774 1-216-296-00 SHORT 0
JC775 1-216-295-00 SHORT 0
JC776 1-216-295-00 SHORT 0
JC777 1-216-295-00 SHORT 0
JC778 1-216-295-00 SHORT 0
< COIL >
L701 1-216-296-00 SHORT 0
L702 1-216-296-00 SHORT 0
L703 1-216-295-00 SHORT 0
L704 1-216-295-00 SHORT 0
L705 1-216-296-00 SHORT 0
L706 1-216-296-00 SHORT 0
L707 1-216-296-00 SHORT 0
L708 1-216-296-00 SHORT 0
L709 1-216-296-00 SHORT 0
L710 1-216-296-00 SHORT 0
L711 1-216-296-00 SHORT 0
< TRANSISTOR >
Q701 8-729-903-46 TRANSISTOR 2SB1132-T100-QR
Q702 8-729-900-53 TRANSISTOR DTC114EKA-T146
< RESISTOR >
R701 1-216-254-00 RES-CHIP 220K 5% 1/8W
R702 1-216-254-00 RES-CHIP 220K 5% 1/8W
R703 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R704 1-216-059-00 METAL CHIP 2.7K 5% 1/10W
R705 1-216-089-11 RES-CHIP 47K 5% 1/10W
R708 1-216-001-00 METAL CHIP 10 5% 1/10W
R709 1-216-234-00 RES-CHIP 33K 5% 1/8W
R712 1-216-222-00 RES-CHIP 10K 5% 1/8W
R713 1-216-085-00 METAL CHIP 33K 5% 1/10W
R714 1-216-099-00 METAL CHIP 120K 5% 1/10W
R715 1-216-085-00 METAL CHIP 33K 5% 1/10W
R716 1-216-085-00 METAL CHIP 33K 5% 1/10W
R717 1-216-073-00 METAL CHIP 10K 5% 1/10W
R718 1-216-097-11 RES-CHIP 100K 5% 1/10W
R719 1-216-270-00 RES-CHIP 1M 5% 1/8W
R720 1-216-073-00 METAL CHIP 10K 5% 1/10W
R721 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R722 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R723 1-216-075-00 METAL CHIP 12K 5% 1/10W
R724 1-216-075-00 METAL CHIP 12K 5% 1/10W
R725 1-216-075-00 METAL CHIP 12K 5% 1/10W
