Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
CONTROL
R726 1-216-075-00 METAL CHIP 12K 5% 1/10W
R727 1-216-075-00 METAL CHIP 12K 5% 1/10W
R728 1-216-075-00 METAL CHIP 12K 5% 1/10W
R730 1-216-065-11 RES-CHIP 4.7K 5% 1/10W
R731 1-216-238-11 RES-CHIP 47K 5% 1/8W
R741 1-216-037-00 METAL CHIP 330 5% 1/10W
R759 1-216-097-11 RES-CHIP 100K 5% 1/10W
R760 1-216-246-00 RES-CHIP 100K 5% 1/8W
R761 1-216-097-11 RES-CHIP 100K 5% 1/10W
R762 1-216-246-00 RES-CHIP 100K 5% 1/8W
R774 1-216-055-00 METAL CHIP 1.8K 5% 1/10W
R775 1-216-049-11 RES-CHIP 1K 5% 1/10W
R776 1-216-065-11 RES-CHIP 4.7K 5% 1/10W
R777 1-216-055-00 METAL CHIP 1.8K 5% 1/10W
R779 1-216-049-11 RES-CHIP 1K 5% 1/10W
R780 1-216-065-11 RES-CHIP 4.7K 5% 1/10W
R781 1-216-049-11 RES-CHIP 1K 5% 1/10W
R782 1-216-055-00 METAL CHIP 1.8K 5% 1/10W
R783 1-216-089-11 RES-CHIP 47K 5% 1/10W
R785 1-216-222-00 RES-CHIP 10K 5% 1/8W
R786 1-216-065-11 RES-CHIP 4.7K 5% 1/10W
R787 1-216-206-00 RES-CHIP 2.2K 5% 1/8W
R788 1-216-049-11 RES-CHIP 1K 5% 1/10W
R790 1-216-049-11 RES-CHIP 1K 5% 1/10W
R791 1-216-246-00 RES-CHIP 100K 5% 1/8W
R799 1-216-089-11 RES-CHIP 47K 5% 1/10W
< SWITCH >
S702 1-762-812-11 SWITCH, LEAF (LIMIT)
< VIBRATOR >
X701 1-577-253-11 VIBRATOR, CERAMIC (16.9344MHz)
*************************************************************
* A-3322-447-A CONTROL BOARD, COMPLETE (S22L)
* A-3322-470-A CONTROL BOARD, COMPLETE (S32L)
*************************
< CAPACITOR >
C602 1-161-494-00 CERAMIC 0.022uF 25V
(S32L)
< CONNECTOR >
* CNP601 1-770-516-31 CONNECTOR, FFC/FPC 8P (S32L)
CNP601 1-770-540-31 CONNECTOR, FFC/FPC 6P (S22L)
< DIODE >
D601 8-719-059-97 LED L-34HD (OPR/BATT)
< IC >
IC601 8-749-014-88 IC SPS-440-E (S32L)
< RESISTOR >
R601 1-249-415-11 CARBON 680 5% 1/4W
R602 1-249-416-11 CARBON 820 5% 1/4W
R603 1-249-418-11 CARBON 1.2K 5% 1/4W
R604 1-249-420-11 CARBON 1.8K 5% 1/4W
R605 1-249-429-11 CARBON 10K 5% 1/4W
R606 1-249-432-11 CARBON 18K 5% 1/4W
R607 1-249-415-11 CARBON 680 5% 1/4W
R608 1-249-416-11 CARBON 820 5% 1/4W
R609 1-249-418-11 CARBON 1.2K 5% 1/4W
R610 1-249-420-11 CARBON 1.8K 5% 1/4W
R611 1-247-843-11 CARBON 3.3K 5% 1/4W
R612 1-249-427-11 CARBON 6.8K 5% 1/4W
R613 1-249-432-11 CARBON 18K 5% 1/4W
R616 1-249-415-11 CARBON 680 5% 1/4W
R617 1-249-424-11 CARBON 3.9K 5% 1/4W
R618 1-247-843-11 CARBON 3.3K 5% 1/4W
R619 1-249-427-11 CARBON 6.8K 5% 1/4W
R620 1-249-432-11 CARBON 18K 5% 1/4W
R621 1-249-415-11 CARBON 680 5% 1/4W
R622 1-249-416-11 CARBON 820 5% 1/4W
R623 1-249-418-11 CARBON 1.2K 5% 1/4W
R624 1-249-420-11 CARBON 1.8K 5% 1/4W
R625 1-247-843-11 CARBON 3.3K 5% 1/4W
R626 1-249-427-11 CARBON 6.8K 5% 1/4W
R627 1-249-432-11 CARBON 18K 5% 1/4W
R628 1-247-815-11 CARBON 220 5% 1/4W
R629 1-247-826-00 CARBON 620 5% 1/4W
R630 1-249-437-11 CARBON 47K 5% 1/4W
(S32L)
< SWITCH >
S601 1-762-798-11 SWITCH, KEY BOARD (OPERATE)
S602 1-762-798-11 SWITCH, KEY BOARD (SLEEP)
S603 1-762-798-11 SWITCH, KEY BOARD (+ VOLUME)
S604 1-762-798-11 SWITCH, KEY BOARD (– VOLUME)
S605 1-762-798-11 SWITCH, KEY BOARD (MEGA BASS) (S32L)
S606 1-762-798-11 SWITCH, KEY BOARD (MEGA BASS) (S22L)
S607 1-762-798-11 SWITCH, KEY BOARD (N X)
S608 1-762-798-11 SWITCH, KEY BOARD (x)
S609 1-762-798-11 SWITCH, KEY BOARD (> + TUNING)
S610 1-762-798-11 SWITCH, KEY BOARD (– . TUNING)
S611 1-762-798-11 SWITCH, KEY BOARD
(PLAY MODE MONO/ST ISS)
S612 1-762-798-11 SWITCH, KEY BOARD (DISPLAY ENT MEMORY)
S613 1-762-798-11 SWITCH, KEY BOARD (CD)
S614 1-762-798-11 SWITCH, KEY BOARD
(RADIO BAND AUTO PRESET)
S615 1-762-798-11 SWITCH, KEY BOARD (TAPE)
S616 1-762-798-11 SWITCH, KEY BOARD (9)
S617 1-762-798-11 SWITCH, KEY BOARD (0/10)
S618 1-762-798-11 SWITCH, KEY BOARD (>10)
S619 1-762-798-11 SWITCH, KEY BOARD (1)
