– 59 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
S620 1-762-798-11 SWITCH, KEY BOARD (2)
S621 1-762-798-11 SWITCH, KEY BOARD (3)
S622 1-762-798-11 SWITCH, KEY BOARD (4)
S623 1-762-798-11 SWITCH, KEY BOARD (5)
S624 1-762-798-11 SWITCH, KEY BOARD (6)
S625 1-762-798-11 SWITCH, KEY BOARD (7)
S626 1-762-798-11 SWITCH, KEY BOARD (8)
S627 1-762-798-11 SWITCH, KEY BOARD (TONE) (S32L)
*************************************************************
* 1-676-628-11 HALF BATTERY BOARD
*******************
3-028-154-01 TERMINAL (–), BATTERY
< CONNECTOR >
* CNP904 1-580-163-11 PIN, CONNECTOR (PC BOARD) 2P
*************************************************************
* 1-676-531-11 LCD BOARD
**********
* 3-041-646-01 HOLDER (LCD)
< CONNECTOR >
CNP651 1-568-864-11 CONNECTOR, FFC 21P
< LIQUID CRYSTAL DISPLAY >
LCD501 1-803-873-11 DISPLAY PANEL, LIQUID CRYSTAL
*************************************************************
* A-3322-561-A MAIN BOARD, COMPLETE (S22L)
* A-3322-603-A MAIN BOARD, COMPLETE (S32L)
*********************
7-685-645-79 SCREW +BVTP 3X6 TYPE2 N-S
< CAPACITOR >
C121 1-126-956-11 ELECT 0.1uF 20% 50V
C122 1-162-294-31 CERAMIC 0.001uF 10% 50V
C123 1-126-961-11 ELECT 2.2uF 20% 50V
C124 1-127-876-21 CERAMIC 0.01uF 10% 50V
C125 1-162-302-11 CERAMIC 0.0022uF 30% 16V
C126 1-126-960-11 ELECT 1uF 20% 50V
C127 1-127-888-21 CERAMIC 0.1uF 10% 50V
(S32L)
C128 1-162-294-31 CERAMIC 0.001uF 10% 50V
C129 1-104-664-11 ELECT 47uF 20% 10V
C130 1-104-665-11 ELECT 100uF 20% 10V
C131 1-126-926-11 ELECT 1000uF 20% 10V
C132 1-136-165-00 MYLAR 0.1uF 5% 50V
C221 1-126-956-11 ELECT 0.1uF 20% 50V
C222 1-162-294-31 CERAMIC 0.001uF 10% 50V
C223 1-126-961-11 ELECT 2.2uF 20% 50V
C224 1-127-876-21 CERAMIC 0.01uF 10% 50V
C225 1-162-302-11 CERAMIC 0.0022uF 30% 16V
C226 1-126-960-11 ELECT 1uF 20% 50V
C227 1-127-888-21 CERAMIC 0.1uF 10% 50V
(S32L)
C228 1-162-294-31 CERAMIC 0.001uF 10% 50V
C229 1-104-664-11 ELECT 47uF 20% 10V
C230 1-104-665-11 ELECT 100uF 20% 10V
C231 1-126-926-11 ELECT 1000uF 20% 10V
C232 1-136-165-00 MYLAR 0.1uF 5% 50V
C321 1-126-934-11 ELECT 220uF 20% 10V
C322 1-104-664-11 ELECT 47uF 20% 10V
C323 1-126-964-11 ELECT 10uF 20% 50V
C324 1-162-306-11 CERAMIC 0.01uF 20% 16V
C325 1-126-937-11 ELECT 4700uF 20% 16V
C326 1-126-934-11 ELECT 220uF 20% 16V
C327 1-162-282-31 CERAMIC 100PF 10% 50V
C328 1-162-282-31 CERAMIC 100PF 10% 50V
C329 1-162-306-11 CERAMIC 0.01uF 20% 16V
C331 1-104-664-11 ELECT 47uF 20% 10V
C335 1-104-664-11 ELECT 47uF 20% 10V
(S32L)
C501 1-126-933-11 ELECT 100uF 20% 16V
C502 1-162-306-11 CERAMIC 0.01uF 20% 16V
C503 1-104-665-11 ELECT 100uF 20% 10V
C504 1-104-665-11 ELECT 100uF 20% 10V
C505 1-162-306-11 CERAMIC 0.01uF 20% 16V
C506 1-162-201-31 CERAMIC 12PF 5% 50V
C507 1-162-201-31 CERAMIC 12PF 5% 50V
C508 1-126-960-11 ELECT 1uF 20% 50V
C513 1-128-802-21 CERAMIC 27PF 5% 50V
C514 1-128-802-21 CERAMIC 27PF 5% 50V
C518 1-126-964-11 ELECT 10uF 20% 50V
C519 1-126-964-11 ELECT 10uF 20% 50V
(S32L)
C520 1-104-664-11 ELECT 47uF 20% 10V
(S32L)
C522 1-104-665-11 ELECT 100uF 20% 10V
C531 1-162-282-31 CERAMIC 100PF 10% 50V
C532 1-162-286-21 CERAMIC 220PF 10% 50V
C533 1-162-282-31 CERAMIC 100PF 10% 50V
C535 1-162-282-31 CERAMIC 100PF 10% 50V
C536 1-162-282-31 CERAMIC 100PF 10% 50V
C537 1-162-282-31 CERAMIC 100PF 10% 50V
C538 1-162-306-11 CERAMIC 0.01uF 20% 16V
C540 1-162-306-11 CERAMIC 0.01uF 20% 16V
C541 1-126-960-11 ELECT 1uF 20% 50V
C542 1-162-306-11 CERAMIC 0.01uF 20% 16V
C543 1-162-282-31 CERAMIC 100PF 10% 50V
C544 1-162-282-31 CERAMIC 100PF 10% 50V
C545 1-162-294-31 CERAMIC 0.001uF 10% 50V
C547 1-162-306-11 CERAMIC 0.01uF 20% 16V
C951 1-162-306-11 CERAMIC 0.01uF 20% 16V
C952 1-162-306-11 CERAMIC 0.01uF 20% 16V
C953 1-126-934-11 ELECT 220uF 20% 10V
