– 61 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
R502 1-249-417-11 CARBON 1K 5% 1/4W
(S32L)
R503 1-249-417-11 CARBON 1K 5% 1/4W
R504 1-249-441-11 CARBON 100K 5% 1/4W
R505 1-249-417-11 CARBON 1K 5% 1/4W
R506 1-249-417-11 CARBON 1K 5% 1/4W
R507 1-249-417-11 CARBON 1K 5% 1/4W
R508 1-249-417-11 CARBON 1K 5% 1/4W
R509 1-249-417-11 CARBON 1K 5% 1/4W
R510 1-249-417-11 CARBON 1K 5% 1/4W
R511 1-249-417-11 CARBON 1K 5% 1/4W
R512 1-249-417-11 CARBON 1K 5% 1/4W
R513 1-249-417-11 CARBON 1K 5% 1/4W
R514 1-249-417-11 CARBON 1K 5% 1/4W
R515 1-249-417-11 CARBON 1K 5% 1/4W
R516 1-249-417-11 CARBON 1K 5% 1/4W
R517 1-249-417-11 CARBON 1K 5% 1/4W
R518 1-249-417-11 CARBON 1K 5% 1/4W
R519 1-249-417-11 CARBON 1K 5% 1/4W
R520 1-249-417-11 CARBON 1K 5% 1/4W
R521 1-249-417-11 CARBON 1K 5% 1/4W
R522 1-249-417-11 CARBON 1K 5% 1/4W
R523 1-249-429-11 CARBON 10K 5% 1/4W
R524 1-249-417-11 CARBON 1K 5% 1/4W
R525 1-249-417-11 CARBON 1K 5% 1/4W
R526 1-249-417-11 CARBON 1K 5% 1/4W
R527 1-249-417-11 CARBON 1K 5% 1/4W
R528 1-249-417-11 CARBON 1K 5% 1/4W
R529 1-249-417-11 CARBON 1K 5% 1/4W
R530 1-249-429-11 CARBON 10K 5% 1/4W
R534 1-247-843-11 CARBON 3.3K 5% 1/4W
R535 1-249-429-11 CARBON 10K 5% 1/4W
R536 1-249-429-11 CARBON 10K 5% 1/4W
R537 1-249-429-11 CARBON 10K 5% 1/4W
R538 1-249-421-11 CARBON 2.2K 5% 1/4W
R539 1-249-421-11 CARBON 2.2K 5% 1/4W
R540 1-249-417-11 CARBON 1K 5% 1/4W
R541 1-249-417-11 CARBON 1K 5% 1/4W
R562 1-249-425-11 CARBON 4.7K 5% 1/4W
R563 1-249-429-11 CARBON 10K 5% 1/4W
(S32L)
R565 1-249-417-11 CARBON 1K 5% 1/4W
R566 1-249-417-11 CARBON 1K 5% 1/4W
R567 1-249-417-11 CARBON 1K 5% 1/4W
R568 1-249-417-11 CARBON 1K 5% 1/4W
R569 1-249-417-11 CARBON 1K 5% 1/4W
R570 1-249-417-11 CARBON 1K 5% 1/4W
R571 1-249-417-11 CARBON 1K 5% 1/4W
R576 1-247-843-11 CARBON 3.3K 5% 1/4W
R577 1-249-417-11 CARBON 1K 5% 1/4W
R578 1-249-429-11 CARBON 10K 5% 1/4W
R579 1-249-417-11 CARBON 1K 5% 1/4W
R580 1-249-417-11 CARBON 1K 5% 1/4W
R581 1-249-425-11 CARBON 4.7K 5% 1/4W
R582 1-249-429-11 CARBON 10K 5% 1/4W
R583 1-249-425-11 CARBON 4.7K 5% 1/4W
R584 1-249-425-11 CARBON 4.7K 5% 1/4W
R585 1-249-425-11 CARBON 4.7K 5% 1/4W
R586 1-249-425-11 CARBON 4.7K 5% 1/4W
R587 1-249-437-11 CARBON 47K 5% 1/4W
R588 1-249-417-11 CARBON 1K 5% 1/4W
R589 1-249-441-11 CARBON 100K 5% 1/4W
R590 1-247-843-11 CARBON 3.3K 5% 1/4W
R591 1-247-832-11 CARBON 1.1K 5% 1/4W
R592 1-249-421-11 CARBON 2.2K 5% 1/4W
R593 1-247-895-11 CARBON 470K 5% 1/4W
R594 1-249-422-11 CARBON 2.7K 5% 1/4W
R595 1-249-417-11 CARBON 1K 5% 1/4W
(S32L)
R596 1-247-807-31 CARBON 100 5% 1/4W
(S32L)
R597 1-249-417-11 CARBON 1K 5% 1/4W
R598 1-249-437-11 CARBON 47K 5% 1/4W
R599 1-249-425-11 CARBON 4.7K 5% 1/4W
R951 1-249-437-11 CARBON 47K 5% 1/4W
R952 1-249-417-11 CARBON 1K 5% 1/4W
R954 1-247-815-11 CARBON 220 5% 1/4W
R955 1-247-807-31 CARBON 100 5% 1/4W
R956 1-249-393-11 CARBON 10 5% 1/4W
R958 1-249-411-11 CARBON 330 5% 1/4W
R960 1-249-393-11 CARBON 10 5% 1/4W
R961 1-249-417-11 CARBON 1K 5% 1/4W
R997 1-249-429-11 CARBON 10K 5% 1/4W
< VIBRATOR >
X501 1-781-775-11 VIBRATOR, CERAMIC (4.19MHz)
X502 1-781-721-11 VIBRATOR, CRYSTAL (153.6kHz)
*************************************************************
* 1-676-530-11 POWER BOARD
*************
< CAPACITOR >
C908 1-126-964-11 ELECT 10uF 20% 50V
< AC INLET >
0CNJ901 1-526-838-11 INLET, AC 2P (- AC IN)
< CONNECTOR >
* CNP901 1-580-155-11 PIN, CONNECTOR (PC BOARD) 3P
* CNP902 1-580-165-21 PIN, CONNECTOR (PC BOARD) 4P
*************************************************************
POWER
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
