– 62 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
* A-3322-560-A PRE BOARD, COMPLETE
********************
< CAPACITOR >
C101 1-163-011-11 CERAMIC CHIP 0.0015uF 10% 50V
C102 1-104-664-11 ELECT 47uF 20% 10V
C103 1-162-587-11 CERAMIC CHIP 0.039uF 10% 25V
C104 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C105 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C106 1-126-960-11 ELECT 1uF 20% 50V
C201 1-163-011-11 CERAMIC CHIP 0.0015uF 10% 50V
C202 1-104-664-11 ELECT 47uF 20% 10V
C203 1-162-587-11 CERAMIC CHIP 0.039uF 10% 25V
C204 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C205 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C206 1-126-960-11 ELECT 1uF 20% 50V
C301 1-104-665-11 ELECT 100uF 20% 10V
C302 1-104-665-11 ELECT 100uF 20% 10V
C303 1-104-665-11 ELECT 100uF 20% 10V
C304 1-104-664-11 ELECT 47uF 20% 10V
C305 1-137-431-11 MYLAR 560PF 5% 50V
C306 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C307 1-163-011-11 CERAMIC CHIP 0.0015uF 10% 50V
C308 1-163-255-11 CERAMIC CHIP 150PF 5% 50V
C310 1-163-257-11 CERAMIC CHIP 180PF 5% 50V
< CONNECTOR >
CNP301 1-784-774-11 CONNECTOR, FFC 13P
< IC >
IC301 8-759-264-71 IC TA2068N
< TRANSISTOR >
Q301 8-729-281-53 TRANSISTOR 2SC1815GR-TPE2
Q302 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
Q303 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
< RESISTOR >
R101 1-216-077-11 RES-CHIP 15K 5% 1/10W
R102 1-216-023-00 METAL CHIP 82 5% 1/10W
R103 1-216-097-11 RES-CHIP 100K 5% 1/10W
R104 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R105 1-216-077-11 RES-CHIP 15K 5% 1/10W
R106 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R110 1-216-025-11 RES-CHIP 100 5% 1/10W
R111 1-216-067-00 METAL CHIP 5.6K 5% 1/10W
R201 1-216-077-11 RES-CHIP 15K 5% 1/10W
R202 1-216-023-00 METAL CHIP 82 5% 1/10W
R203 1-216-097-11 RES-CHIP 100K 5% 1/10W
R204 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R205 1-216-077-11 RES-CHIP 15K 5% 1/10W
R206 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R210 1-216-174-00 RES-CHIP 100 5% 1/8W
R211 1-216-067-00 METAL CHIP 5.6K 5% 1/10W
R301 1-216-121-11 RES-CHIP 1M 5% 1/10W
R302 1-216-214-00 RES-CHIP 4.7K 5% 1/8W
R303 1-216-214-00 RES-CHIP 4.7K 5% 1/8W
R304 1-216-198-11 RES-CHIP 1K 5% 1/8W
R305 1-216-180-00 RES-CHIP 180 5% 1/8W
R306 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R307 1-216-150-11 RES-CHIP 10 5% 1/8W
R308 1-216-081-00 METAL CHIP 22K 5% 1/10W
R309 1-216-166-00 RES-CHIP 47 5% 1/8W
R310 1-216-121-11 RES-CHIP 1M 5% 1/10W
R311 1-216-121-11 RES-CHIP 1M 5% 1/10W
R312 1-216-049-11 RES-CHIP 1K 5% 1/10W
R313 1-216-049-11 RES-CHIP 1K 5% 1/10W
< SWITCH >
S301 1-762-565-11 SWITCH, SLIDE (REC/PB)
< TRANSFORMER >
T301 1-416-041-11 TRANSFORMER, BIAS OSCILLATION
*************************************************************
* 1-676-629-11 SECONDARY BOARD
*****************
1-533-233-31 HOLDER, FUSE
< CAPACITOR >
C901 1-101-005-00 CERAMIC 22000PF 50V
C902 1-101-005-00 CERAMIC 22000PF 50V
C903 1-101-005-00 CERAMIC 22000PF 50V
C904 1-101-005-00 CERAMIC 22000PF 50V
< DIODE >
D901 8-719-063-79 DIODE 1N4002B
D902 8-719-063-79 DIODE 1N4002B
D903 8-719-063-79 DIODE 1N4002B
D904 8-719-063-79 DIODE 1N4002B
*************************************************************
* A-3322-563-A TUNER BOARD, COMPLETE
***********************
< CAPACITOR >
C1 1-163-263-11 CERAMIC CHIP 330PF 5% 50V
C2 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C3 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C4 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C5 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C6 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C7 1-163-113-00 CERAMIC CHIP 68PF 5% 50V
C8 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C9 1-163-098-00 CERAMIC CHIP 16PF 5% 50V
C10 1-126-960-11 ELECT 1uF 20% 50V
SECONDARY TUNERPRE
