– 63 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
TUNER
C11 1-163-077-00 CERAMIC CHIP 0.1uF 10% 25V
C12 1-126-963-11 ELECT 4.7uF 20% 50V
C14 1-163-023-00 CERAMIC CHIP 0.015uF 5% 50V
C15 1-163-023-00 CERAMIC CHIP 0.015uF 5% 50V
C16 1-126-960-11 ELECT 1uF 20% 50V
C17 1-126-960-11 ELECT 1uF 20% 50V
C18 1-126-934-11 ELECT 220uF 20% 10V
C19 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C20 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C21 1-126-960-11 ELECT 1uF 20% 50V
C22 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C23 1-126-960-11 ELECT 1uF 20% 50V
C24 1-163-003-11 CERAMIC CHIP 330PF 10% 50V
C25 1-163-059-11 CERAMIC CHIP 0.01uF 10% 50V
C28 1-104-665-11 ELECT 100uF 20% 10V
C30 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C31 1-163-237-11 CERAMIC CHIP 27PF 5% 50V
C32 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C33 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C34 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C35 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C40 1-163-098-00 CERAMIC CHIP 16PF 5% 50V
C41 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C42 1-163-130-00 CERAMIC CHIP 360PF 5% 50V
C44 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C45 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C46 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C51 1-163-229-11 CERAMIC CHIP 12PF 5% 50V
C52 1-163-098-00 CERAMIC CHIP 16PF 5% 50V
C53 1-136-171-00 MYLAR 0.33uF 5% 50V
C54 1-126-934-11 ELECT 220uF 20% 10V
C55 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C56 1-163-205-00 CERAMIC CHIP 0.001uF 5% 50V
C57 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C58 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C59 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C60 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C61 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C62 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C63 1-163-181-00 CERAMIC CHIP 100PF 5% 50V
C64 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C66 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C67 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C68 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C77 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C80 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C93 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C95 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
< FILTER >
CF2 1-579-083-11 FILTER, CERAMIC
CF4 1-781-344-12 FILTER, AM CERAMIC
< CONNECTOR >
* CNP1 1-785-663-11 PIN, CONNECTOR (PC BOARD) 11P
< TRIMMER >
CT1 1-141-227-00 CAP, TRIMMER 20PF
CT3 1-141-304-21 CAP, TRIMMER 10PF
CT5 1-141-605-11 CAP, ADJ
< DIODE >
D1 8-719-078-48 DIODE KV1471ETR1-3
D2 8-719-078-48 DIODE KV1471ETR1-3
D3 8-719-050-69 DIODE KV1520NT-2
D10 8-719-988-61 DIODE 1SS355TE-17
D11 8-719-988-61 DIODE 1SS355TE-17
< JUMPER RESISTOR >
FB1 1-216-295-00 SHORT 0
< IC >
IC1 8-759-662-67 IC TA2149N
IC2 8-759-483-40 IC LC72137M-TLM
< JUMPER RESISTOR >
JC3 1-216-295-00 SHORT 0
JC4 1-216-296-00 SHORT 0
JC6 1-216-296-00 SHORT 0
JC7 1-216-296-00 SHORT 0
JC8 1-216-296-00 SHORT 0
JC9 1-216-296-00 SHORT 0
JC10 1-216-296-00 SHORT 0
JC13 1-216-296-00 SHORT 0
JC14 1-216-296-00 SHORT 0
JC15 1-216-296-00 SHORT 0
JC16 1-216-296-00 SHORT 0
JC19 1-216-296-00 SHORT 0
JC20 1-216-296-00 SHORT 0
JC23 1-216-296-00 SHORT 0
JC24 1-216-295-00 SHORT 0
JC25 1-216-296-00 SHORT 0
JC27 1-216-296-00 SHORT 0
JC28 1-216-296-00 SHORT 0
JC29 1-216-296-00 SHORT 0
JC30 1-216-296-00 SHORT 0
JC31 1-216-296-00 SHORT 0
JC33 1-216-296-00 SHORT 0
JC38 1-216-296-00 SHORT 0
JC39 1-216-296-00 SHORT 0
JC40 1-216-296-00 SHORT 0
JC41 1-216-296-00 SHORT 0
JC43 1-216-296-00 SHORT 0
JC44 1-216-295-00 SHORT 0
JC45 1-216-295-00 SHORT 0
