– 58 –
R814 1-247-843-11 CARBON 3.3K 5% 1/4W
R815 1-249-428-11 CARBON 8.2K 5% 1/4W
R817 1-249-418-11 CARBON 1.2K 5% 1/4W
R818 1-249-420-11 CARBON 1.8K 5% 1/4W
R819 1-247-843-11 CARBON 3.3K 5% 1/4W
R820 1-249-428-11 CARBON 8.2K 5% 1/4W
R821 1-247-828-11 CARBON 750 5% 1/4W
R822 1-247-816-11 CARBON 240 5% 1/4W
< SWITCH >
S801 1-762-798-11 SWITCH, KEYBOARD (POWER)
S802 1-762-798-11 SWITCH, KEYBOARD (CLOCK)
S803 1-762-798-11 SWITCH, KEYBOARD (STANDBY)
S804 1-762-798-11 SWITCH, KEYBOARD (BAND)
S805 1-762-798-11 SWITCH, KEYBOARD (WAKE UP)
S806 1-762-798-11 SWITCH, KEYBOARD (SLEEP)
S807 1-762-798-11 SWITCH, KEYBOARD (π)
S808 1-762-798-11 SWITCH, KEYBOARD (fl)
S809 1-762-798-11 SWITCH, KEYBOARD (FUNCTION)
S810 1-762-798-11 SWITCH, KEYBOARD (PRESET –)
S811 1-762-798-11 SWITCH, KEYBOARD (PRESET +)
S812 1-762-798-11 SWITCH, KEYBOARD (DISPLAY ENT MEM)
S813 1-762-798-11 SWITCH, KEYBOARD (≠/ – )
S814 1-762-798-11 SWITCH, KEYBOARD (±/ + )
S815 1-762-798-11 SWITCH, KEYBOARD
(PLAY MODE, MONO/ST ISS)
S816 1-762-798-11 SWITCH, KEYBOARD (VOL – )
S817 1-762-798-11 SWITCH, KEYBOARD (VOL + )
S818 1-762-798-11 SWITCH, KEYBOARD (SOUND)
S819 1-762-798-11 SWITCH, KEYBOARD (MEGA BASS)
************************************************************
* A-3306-318-A TUNER BOARD, COMPLETE (EXCEPT AUS)
* A-3306-680-A TUNER BOARD, COMPLETE (AUS)
**********************
1-782-112-11 WIRE, PARALLEL (FFC) (13 CORE)
7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S
< CAPACITOR >
C2 1-162-294-31 CERAMIC 0.001uF 10% 50V
C3 1-162-306-11 CERAMIC 0.01uF 20% 16V
C4 1-102-516-11 CERAMIC 27PF 5% 50V
C5 1-162-203-31 CERAMIC 15PF 5% 50V
C7 1-162-839-11 CERAMIC 0.01uF 10% 16V
C8 1-162-201-31 CERAMIC 12PF 5% 50V
C9 1-102-820-00 CERAMIC 330PF 5% 50V
C10 1-164-159-11 CERAMIC 0.1uF 50V
C11 1-162-288-31 CERAMIC 330PF 10% 50V
C12 1-124-907-11 ELECT 10uF 20% 50V
C13 1-162-306-11 CERAMIC 0.01uF 20% 16V
C14 1-162-849-11 CERAMIC 0.068uF 10% 50V
C15 1-162-850-11 CERAMIC 0.082uF 10% 16V
C16 1-162-850-11 CERAMIC 0.082uF 10% 16V
C17 1-126-963-11 ELECT 4.7uF 20% 50V
C18 1-104-664-11 ELECT 47uF 20% 10V
C19 1-162-306-11 CERAMIC 0.01uF 20% 16V
C22 1-162-306-11 CERAMIC 0.01uF 20% 16V
C23 1-161-053-00 CERAMIC 0.015uF 10% 50V
C24 1-161-053-00 CERAMIC 0.015uF 10% 50V
C26 1-126-963-11 ELECT 4.7uF 20% 50V
C27 1-126-963-11 ELECT 4.7uF 20% 50V
C44 1-162-839-11 CERAMIC 0.01uF 10% 16V
C45 1-136-177-00 FILM 1uF 5% 50V
C46 1-126-963-11 ELECT 4.7uF 20% 50V
C47 1-162-306-11 CERAMIC 0.01uF 20% 16V
C48 1-126-963-11 ELECT 4.7uF 20% 50V
C49 1-162-306-11 CERAMIC 0.01uF 20% 16V
C50 1-162-294-31 CERAMIC 0.001uF 10% 50V
C51 1-162-294-31 CERAMIC 0.001uF 10% 50V
C53 1-162-294-31 CERAMIC 0.001uF 10% 50V
C54 1-102-518-11 CERAMIC 33PF 5% 50V
C55 1-162-199-31 CERAMIC 10PF 5% 50V
C56 1-162-290-31 CERAMIC 470PF 10% 50V
(FORMER TYPE)
C56 1-162-306-11 CERAMIC 0.01uF 20% 16V
(NEW TYPE)
C57 1-162-290-31 CERAMIC 470PF 10% 50V
(EXCEPT AUS)
C58 1-162-306-11 CERAMIC 0.01uF 20% 16V
C59 1-162-306-11 CERAMIC 0.01uF 20% 16V
C60 1-124-907-11 ELECT 10uF 20% 50V
C62 1-162-306-11 CERAMIC 0.01uF 20% 16V
C63 1-164-159-11 CERAMIC 0.1uF 50V
C64 1-162-198-31 CERAMIC 8.2PF 10% 50V
C65 1-162-282-31 CERAMIC 100PF 10% 50V
C66 1-162-839-11 CERAMIC 0.01uF 10% 16V
C68 1-162-215-31 CERAMIC 47PF 5% 50V
C69 1-162-839-11 CERAMIC 0.01uF 10% 16V
C70 1-162-839-11 CERAMIC 0.01uF 10% 16V
C71 1-162-294-31 CERAMIC 0.001uF 10% 50V
C72 1-162-294-31 CERAMIC 0.001uF 10% 50V
C77 1-162-201-31 CERAMIC 12PF 5% 50V
< FILTER >
CF1 1-760-738-11 FILTER, CERAMIC (AUS)
CF1 1-767-441-11 FILTER, CERAMIC (EXCEPT AUS)
CF2 1-760-738-11 FILTER, CERAMIC (AUS)
CF2 1-767-441-11 FILTER, CERAMIC (EXCEPT AUS)
CF4 1-767-096-11 VIBRATOR, CERAMIC
< COMPOSITION CIRCUIT BLOCK >
CFT1 1-233-885-11 ENCAPSULATED COMPONENT
< CONNECTOR >
CN1 1-569-930-11 HOUSING, CONNECTOR 13P
< TRIMMER >
CT1 1-141-227-00 CAP, TRIMMER 20PF
CT2 1-141-227-00 CAP, TRIMMER 20PF
< DIODE >
D1 8-719-050-72 DIODE KV1370NT
D2 8-719-050-72 DIODE KV1370NT
D3 8-719-050-69 DIODE KV1520N
D6 8-719-991-33 DIODE 1SS133T-77
D7 8-719-991-33 DIODE 1SS133T-77
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
SW TUNER
