– 59 –
< FILTER >
FL1 1-236-022-11 FILTER, BAND PASS
< IC >
IC1 8-759-386-02 IC TA2008AN
IC3 8-759-333-33 IC BU2614
< COIL >
L1 1-409-905-31 COIL, FM RF
L2 1-409-904-31 COIL, FM OSC
L3 1-501-923-11 ANTENNA, FERRITE-ROD (AM)
L4 1-411-234-21 COIL, AM OSC
L5 1-410-336-11 INDUCTOR 220uH
L7 1-410-521-11 INDUCTOR 100uH
< TRANSISTOR >
Q1 8-729-036-77 TRANSISTOR KRC107M
Q2 8-729-036-77 TRANSISTOR KRC107M
Q3 8-729-036-77 TRANSISTOR KRC107M
Q4 8-729-036-77 TRANSISTOR KRC107M
Q10 8-729-036-77 TRANSISTOR KRC107M
Q11 8-729-036-77 TRANSISTOR KRC107M
Q13 8-729-037-34 TRANSISTOR KRA107M
Q14 8-729-036-77 TRANSISTOR KRC107M
Q15 8-729-037-34 TRANSISTOR KRA107M
Q16 8-729-012-83 TRANSISTOR 2SK679A
Q17 8-729-106-07 TRANSISTOR 2SK514-H
Q18 8-729-922-66 TRANSISTOR 2SC2410SN
< RESISTOR >
JW52 1-249-429-11 CARBON 10K 5% 1/4W
(NEW TYPE)
R1 1-249-441-11 CARBON 100K 5% 1/4W
R2 1-247-887-00 CARBON 220K 5% 1/4W
R3 1-249-431-11 CARBON 15K 5% 1/4W
R4 1-249-429-11 CARBON 10K 5% 1/4W
R6 1-247-887-00 CARBON 220K 5% 1/4W
R7 1-247-815-91 CARBON 220 5% 1/4W
R8 1-247-863-91 CARBON 22K 5% 1/4W
R9 1-249-421-11 CARBON 2.2K 5% 1/4W
R10 1-249-425-11 CARBON 4.7K 5% 1/4W
R11 1-247-815-91 CARBON 220 5% 1/4W
R12 1-247-843-11 CARBON 3.3K 5% 1/4W
R13 1-247-843-11 CARBON 3.3K 5% 1/4W
R14 1-249-404-00 CARBON 82 5% 1/4W
R16 1-249-429-11 CARBON 10K 5% 1/4W
R17 1-249-429-11 CARBON 10K 5% 1/4W
R21 1-247-883-00 CARBON 150K 5% 1/4W
R25 1-249-417-11 CARBON 1K 5% 1/4W
R26 1-249-425-11 CARBON 4.7K 5% 1/4W
R27 1-249-421-11 CARBON 2.2K 5% 1/4W
R28 1-249-429-11 CARBON 10K 5% 1/4W
R29 1-249-415-11 CARBON 680 5% 1/4W
R30 1-249-412-11 CARBON 390 5% 1/4W
R35 1-249-417-11 CARBON 1K 5% 1/4W
R37 1-249-429-11 CARBON 10K 5% 1/4W
(FORMER TYPE)
R38 1-249-429-11 CARBON 10K 5% 1/4W
R39 1-249-429-11 CARBON 10K 5% 1/4W
R40 1-249-417-11 CARBON 1K 5% 1/4W
R41 1-249-417-11 CARBON 1K 5% 1/4W
R42 1-249-425-11 CARBON 4.7K 5% 1/4W
R43 1-249-437-11 CARBON 47K 5% 1/4W
R44 1-249-429-11 CARBON 10K 5% 1/4W
R45 1-249-441-11 CARBON 100K 5% 1/4W
R46 1-247-863-91 CARBON 22K 5% 1/4W
R55 1-249-421-11 CARBON 2.2K 5% 1/4W
R56 1-249-407-11 CARBON 150 5% 1/4W
R57 1-249-399-11 CARBON 33 5% 1/4W
R58 1-249-411-11 CARBON 330 5% 1/4W
R59 1-249-437-11 CARBON 47K 5% 1/4W
R60 1-249-425-11 CARBON 4.7K 5% 1/4W
R61 1-249-437-11 CARBON 47K 5% 1/4W
< TRANSFORMER >
T1 1-409-944-11 COIL (DET)
< VIBRATOR >
X1 1-760-130-11 VIBRATOR, CRYSTAL (75kHz)
************************************************************
MISCELLANEOUS
***************
55 1-452-899-11 MAGNET
70 1-777-955-11 WIRE (FLAT TYPE) (16 CORE)
103 1-533-233-31 HOLDER, FUSE
114 1-782-112-11 WIRE, PARALLEL (FFC) (13 CORE)
!254 8-848-483-05 DEVICE,OPTICAL KSS-213C
255 X-2626-202-1 CHASSIS ASSY (MB) (RP),
MOTOR (INCLUDING M702) (SPINDLE)
ANT1 1-501-918-11 ANTENNA, TELESCOPIC
C851 1-162-199-31 CERAMIC 10PF 5% 50V
!F902 1-532-464-31 FUSE, TIME LAG (T2.5AL/250V)
HE901 1-543-876-11 HEAD (ERASE)
HRP901 1-500-454-11 HEAD,MAGNETIC(RECORD/PLAYBACK)
LCD801 1-801-592-11 DISPLAY PANEL, LIQUID CRYSTAL
M701 X-2625-769-1 GEAR ASSY (MB) (RP), MOTOR (SLED)
M901 A-3320-446-A MOTOR ASSY (INCLUDING MOTOR PULLEY)
S871 1-692-960-11 SWITCH, PUSH (1 KEY) (DOOR OPEN/CLOSE)
S901 1-762-679-11 SWITCH, LEAF (MOTOR ON/OFF)
S902 1-771-059-11 SWITCH, LEAF (TAPE PLAY)
SP901 1-505-531-11 SPEAKER (10CM) (L-CH)
SP902 1-505-531-11 SPEAKER (10CM) (R-CH)
!T901 1-427-943-11 TRANSFORMER, POWER
************************************************************
ACCESSORIES & PACKING MATERIALS
*******************************
! 1-696-819-11 CORD, POWER (AUS)
! 1-769-412-11 CORD, POWER (EXCEPT AUS)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
TUNER
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
