CFD-V3/V7/V7L
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R315 1-216-821-11 METAL CHIP 1K 5% 1/16W
R319 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R340 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R341 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R342 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R343 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
(-11)
R343 1-216-821-11 METAL CHIP 1K 5% 1/16W
(V7:IT)
R344 1-216-813-11 METAL CHIP 220 5% 1/16W
R345 1-216-821-11 METAL CHIP 1K 5% 1/16W
R346 1-216-821-11 METAL CHIP 1K 5% 1/16W
(EXCEPT IT)(-12)
R348 1-216-821-11 METAL CHIP 1K 5% 1/16W
(EXCEPT IT)(-12)
R349 1-216-815-11 METAL CHIP 330 5% 1/16W
R350 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R351 1-216-821-11 METAL CHIP 1K 5% 1/16W
(-11)
R351 1-216-819-11 METAL CHIP 680 5% 1/16W
(-12)
R352 1-216-821-11 METAL CHIP 1K 5% 1/16W
(-11)
R352 1-216-819-11 METAL CHIP 680 5% 1/16W
(-12)
R353 1-216-821-11 METAL CHIP 1K 5% 1/16W
(-11)
R353 1-216-819-11 METAL CHIP 680 5% 1/16W
(-12)
R354 1-216-819-11 METAL CHIP 1K 5% 1/16W
(-11)
R354 1-216-819-11 METAL CHIP 680 5% 1/16W
(-12)
R355 1-216-821-11 METAL CHIP 1K 5% 1/16W
(-11)
R360 1-216-845-11 METAL CHIP 100K 5% 1/16W
R386 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R401 1-216-845-11 METAL CHIP 100K 5% 1/16W
R402 1-216-833-11 METAL CHIP 10K 5% 1/16W
R403 1-216-837-11 METAL CHIP 22K 5% 1/16W
R404 1-216-821-11 METAL CHIP 1K 5% 1/16W
R413 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
(-11)
R414 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
(-11)
R415 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
(-11)
R415 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
(-12)
R416 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R417 1-216-833-11 METAL CHIP 10K 5% 1/16W
R418 1-216-833-11 METAL CHIP 10K 5% 1/16W
R801 1-216-801-11 METAL CHIP 22 5% 1/16W
R805 1-216-849-11 METAL CHIP 220K 5% 1/16W
R806 1-216-813-11 METAL CHIP 220 5% 1/16W
R809 1-216-821-11 METAL CHIP 1K 5% 1/16W
R810 1-216-809-11 METAL CHIP 100 5% 1/16W
R811 1-216-833-11 METAL CHIP 10K 5% 1/16W
R812 1-216-821-11 METAL CHIP 1K 5% 1/16W
R813 1-216-821-11 METAL CHIP 1K 5% 1/16W
R814 1-216-821-11 METAL CHIP 1K 5% 1/16W
R815 1-216-809-11 METAL CHIP 100 5% 1/16W
R816 1-216-809-11 METAL CHIP 100 5% 1/16W
R818 1-216-809-11 METAL CHIP 100 5% 1/16W
R819 1-216-809-11 METAL CHIP 100 5% 1/16W
R851 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
<SWITCH>
S351 1-572-300-11 SWITCH, LEVER SLIDE (FUNCTION)
<TRANSFORMER>
T1 1-424-702-11 COIL, FM DET (FM IF)
T2 1-424-703-11 COIL, AM IFT (AM/LW IF)
*****************************************************
*
A-3062-296-A PRE BOARD, COMPLETE (V7L)
* A-3347-104-A PRE BOARD, COMPLETE (V3/V7)
************************
<CAPACITOR>
C101 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C102 1-104-664-11 ELECT 47uF 20% 10V
C103 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C104 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C105 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C106 1-126-960-11 ELECT 1uF 20% 50V
C107 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C201 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C202 1-104-664-11 ELECT 47uF 20% 10V
C203 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C204 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C205 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C206 1-126-960-11 ELECT 1uF 20% 50V
C207 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C301 1-104-665-11 ELECT 100uF 20% 10V
C302 1-104-665-11 ELECT 100uF 20% 10V
C303 1-104-665-11 ELECT 100uF 20% 10V
C304 1-104-664-11 ELECT 47uF 20% 10V
C305 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C306 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C307 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C310 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
(V7L)
<CONNECTOR>
CN303 1-695-371-31 CONNECTOR, FFC 10P (V3/V7)
CN302 1-784-773-11 CONNECTOR, FFC 12P (V7L)
<IC>
IC301 8-759-264-71 IC TA2068N
<JUMPER RESISTOR>
JC301 1-216-864-11 SHORT 0
JC302 1-216-864-11 SHORT 0
JC303 1-216-864-11 SHORT 0
JC304 1-216-864-11 SHORT 0
JC309 1-216-864-11 SHORT 0 (V7L)
Ver 1.5
MAIN PRE
