– 7 – – 8 –
NOTE :
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms
METAL : Metal-film resistor
METAL OXIDE :Metal oxide-film resistor
F : nonflammable
• Items marked “ * ”are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering
these items.
• SEMICONDUCTORS
In each case, u : µ , for example :
uA.... : µ A.... , uPA.... : µ PA....
uPB.... : µ PB.... , uPC.... : µ PC....
uPD.... : µ PD....
• CAPACITORS
uF : µ F
• COILS
uH : µ H
When indicating parts by reference num-
ber, please include the board.
r
ELECTRICAL PARTS LIST (US, Canadian, C&SA model only) (Service Manual See page 19 to 21)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
* A-3305-480-A MAIN BOARD, COMPLETE
*********************
* 3-913-791-01 HOLDER, BAR ANTENNA
7-621-770-87 SCREW +B 2.6X5
< CAPACITOR >
C1 1-162-206-31 CERAMIC 20PF 5% 50V
C2 1-102-953-00 CERAMIC 18PF 5% 50V
C3 1-102-852-91 CERAMIC 47PF 5% 50V
C5 1-162-191-31 CERAMIC 2.2PF 10% 50V
C6 1-162-196-31 CERAMIC 5.6PF 10% 50V
C9 1-162-286-21 CERAMIC 220PF 10% 50V
C10 1-104-666-11 ELECT 220uF 20% 6.3V
C11 1-104-663-11 ELECT 33uF 20% 16V
C13 1-162-600-11 CERAMIC 0.0047uF 30% 16V
C15 1-162-306-11 CERAMIC 0.01uF 30% 16V
C16 1-162-306-11 CERAMIC 0.01uF 30% 16V
C20 1-162-306-11 CERAMIC 0.01uF 30% 16V
C21 1-162-294-31 CERAMIC 0.001uF 10% 50V
C22 1-126-959-11 ELECT 0.47uF 20% 50V
C23 1-162-193-31 CERAMIC 3.3PF 10% 50V
C24 1-162-294-31 CERAMIC 0.001uF 10% 50V
C25 1-162-306-11 CERAMIC 0.01uF 30% 16V
C26 1-104-663-11 ELECT 33uF 20% 16V
C28 1-162-306-11 CERAMIC 0.01uF 30% 16V
C29 1-162-306-11 CERAMIC 0.01uF 30% 16V
C40 1-162-294-31 CERAMIC 0.001uF 10% 50V
C41 1-162-282-31 CERAMIC 100PF 10% 50V
C42 1-162-306-11 CERAMIC 0.01uF 30% 16V
C101 1-162-843-11 CERAMIC 0.022uF 10% 16V
C102 1-126-233-11 ELECT 22uF 20% 50V
C103 1-162-843-11 CERAMIC 0.022uF 10% 16V
C104 1-126-233-11 ELECT 22uF 20% 50V
C105 1-126-961-11 ELECT 2.2uF 20% 50V
C106 1-161-045-00 CERAMIC 0.0033uF 10% 50V
C107 1-161-043-00 CERAMIC 0.0022uF 10% 50V
C108 1-104-664-11 ELECT 47uF 20% 10V
C109 1-126-959-11 ELECT 0.47uF 20% 50V
C110 1-130-487-00 MYLAR 0.022uF 5% 50V
C111 1-126-233-11 ELECT 22uF 20% 50V
C112 1-162-294-31 CERAMIC 0.001uF 10% 50V
C113 1-124-443-00 ELECT 100uF 20% 10V
C116 1-162-600-11 CERAMIC 0.0047uF 30% 16V
C117 1-124-472-11 ELECT 470uF 20% 10V
C118 1-126-233-11 ELECT 22uF 20% 50V
C119 1-136-171-00 FILM 0.33uF 5% 50V
C120 1-126-768-11 ELECT 2200uF 20% 16V
C121 1-126-959-11 ELECT 0.47uF 20% 50V
C122 1-162-841-11 CERAMIC 0.015uF 10% 16V
C123 1-162-282-31 CERAMIC 100PF 10% 50V
C124 1-162-294-31 CERAMIC 0.001uF 10% 50V
C125 1-162-282-31 CERAMIC 100PF 10% 50V
C126 1-162-286-21 CERAMIC 220PF 10% 50V
C127 1-162-282-31 CERAMIC 100PF 10% 50V
C128 1-162-282-31 CERAMIC 100PF 10% 50V
C129 1-162-286-21 CERAMIC 220PF 10% 50V
C130 1-124-472-11 ELECT 470uF 20% 10V
C131 1-162-832-11 CERAMIC 0.0027uF 10% 0
C132 1-136-167-00 FILM 0.15uF 5% 50V
C133 1-136-167-00 FILM 0.15uF 5% 50V
< FILTER >
CF1 1-567-390-11 FILTER,CERAMIC 10.7M
CF2 1-577-072-11 FILTER, CERAMIC
< CONNECTOR >
CN101 1-695-105-11 PIN, CONNECTOR (PC BOARD) 3P
* CN102 1-566-779-11 PIN, CONNECTOR (PC BOARD) 4P
* CN104 1-580-154-11 PIN, CONNECTOR (PC BOARD) 2P
< VARIABLE CAPACITOR >
CV1 1-151-628-11 CAP, VARIABLE (TUNING)
CV2 1-151-628-11 CAP, VARIABLE (TUNING)
CV3 1-151-628-11 CAP, VARIABLE (TUNING)
CV4 1-151-628-11 CAP, VARIABLE (TUNING)
< TRIMMER >
CT1 1-151-628-11 CAP, VARIABLE (AM TRACKING)
CT2 1-151-628-11 CAP, VARIABLE (AM FREQUENCY COVERAGE)
CT3 1-151-628-11 CAP, VARIABLE (FM TRACKING)
CT4 1-151-628-11 CAP, VARIABLE (FM FREQUENCY COVERAGE)
MAIN
< DIODE >
D101 8-719-057-90 LED L-974HD (OPR/BATT)
D102 8-719-109-75 DIODE RD4.3ES-B2
D103 8-719-055-76 DIODE 1N4148
D104 8-719-055-76 DIODE 1N4148
D105 8-719-055-76 DIODE 1N4148
D108 8-719-109-89 DIODE RD5.6ESB2
D109 8-719-109-81 DIODE RD4.7ESB2
D110 8-719-055-76 DIODE 1N4148
< FILTER >
FL1 1-235-171-00 FILTER, BAND PASS
< IC >
IC1 8-759-245-07 IC TA8164P
IC101 8-759-440-96 IC MM1315AS
< COIL >
L1 1-422-317-31 COIL, AIR-CORE (FM TRACKING)
L2 1-460-205-31 COIL (WITH CORE)
(FM FREQUENCY COVERAGE)
L3 1-501-805-11 ANTENNA, FERRITE-ROD (AM)
(AM TRACKING)
L6 1-406-576-11 COIL, MW OSC (AM FREQUENCY COVERAGE)
L10 1-414-140-11 INDUCTOR 0.68uH
L11 1-414-140-11 INDUCTOR 0.68uH
L12 1-500-419-11 FERRITE
< TRANSISTOR >
Q1 8-729-194-57 TRANSISTOR 2SC945-P
< RESISTOR >
R1 1-249-391-11 CARBON 6.8 5% 1/4W
R2 1-249-404-00 CARBON 82 5% 1/4W
R3 1-249-428-11 CARBON 8.2K 5% 1/4W
R4 1-247-863-91 CARBON 22K 5% 1/4W
R5 1-249-411-11 CARBON 330 5% 1/4W
R6 1-249-437-11 CARBON 47K 5% 1/4W
R7 1-249-437-11 CARBON 47K 5% 1/4W
R8 1-249-437-11 CARBON 47K 5% 1/4W
R9 1-249-411-11 CARBON 330 5% 1/4W
R20 1-249-439-11 CARBON 68K 5% 1/4W
R101 1-249-421-11 CARBON 2.2K 5% 1/4W
R102 1-249-417-11 CARBON 1K 5% 1/4W
R103 1-249-421-11 CARBON 2.2K 5% 1/4W
R104 1-247-854-11 CARBON 9.1K 5% 1/4W
R105 1-249-413-11 CARBON 470 5% 1/4W
R106 1-247-852-11 CARBON 7.5K 5% 1/4W
R107 1-247-807-31 CARBON 100 5% 1/4W
R108 1-247-815-91 CARBON 220 5% 1/4W
R109 1-249-417-11 CARBON 1K 5% 1/4W
R110 1-247-864-11 CARBON 24K 5% 1/4W
R111 1-247-815-91 CARBON 220 5% 1/4W
R113 1-249-401-11 CARBON 47 5% 1/4W
R116 1-249-407-11 CARBON 150 5% 1/4W
R117 1-249-407-11 CARBON 150 5% 1/4W
R118 1-247-897-11 CARBON 560K 5% 1/4W
R119 1-249-414-11 CARBON 560 5% 1/4W
R120 1-249-413-11 CARBON 470 5% 1/4W
R121 1-247-807-31 CARBON 100 5% 1/4W
R122 1-249-414-11 CARBON 560 5% 1/4W
R123 1-249-389-11 CARBON 4.7 5% 1/4W
R124 1-249-389-11 CARBON 4.7 5% 1/4W
R125 1-247-855-11 CARBON 10K 5% 1/4W
< VARIABLE RESISTOR >
RV101 1-223-625-11 RES, VAR, CARBON 20K (VOLUME)
< SWITCH >
S101 1-572-625-11 SWITCH, SLIDE (FUNCTION)
S102 1-762-565-11 SWITCH, SLIDE (PB/REC)
< TRANSFORMER >
T1 1-406-577-11 TRANSFORMER, IF (FM IF)
T2 1-406-575-11 TRANSFORMER, IF (AM IF)
T3 1-406-578-11 COIL, FM DETECTOR (FM IF)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
9-960-488-84
Sony Corporation
Personal Audio Company
99F0218-1
Printed in Japan © 1999.6
Published by General Engineering Dept.
CFM-10/10L
• Abbreviation
C&SA : Central & South America
