– 22 –
CFM-D1
MISCELLANEOUS
**************
55 1-533-233-31 HOLDER, FUSE
ANT1 1-501-668-11 ANTENNA, TELESCOPIC
! F901 1-532-234-31 FUSE, TIME-LAG (0.080A 250V)
HE101 1-500-232-11 HEAD, MAGNETIC (ERASE)
HRP101 1-500-310-11 HEAD, MAGNETIC (RECORD/PLAYBACK)
L5 1-501-705-11 ANTENNA, FERRITE-ROD (MW)
M101 X-3372-889-1 MOTOR ASSY (including PULLEY)
S601 1-692-978-11 SWITCH, LEAF (TAPE SWITCH)
S602 1-692-978-11 SWITCH, LEAF (CUE/REVIEW)
SP101 1-505-202-11 SPEAKER (L-CH)
SP102 1-505-202-11 SPEAKER (R-CH)
************************************************************
ACCESSORIES & PACKING MATERIALS
********************************
! 1-551-983-00 CORD, POWER (E23)
! 1-569-007-11 ADAPTER, CONVERSION 2P (E23)
! 1-569-008-21 ADAPTER, CONVERSION 2P (EA)
! 1-769-412-11 CORD, POWER (E15, EA, SP, UAE)
3-810-800-11 MANUAL, INSTRUCTION
(ENGLISH/FRENCH/SPANISH)
3-810-800-31 MANUAL, INSTRACTION (ARABIC) (EA)
* 3-934-613-01 CARTON, INDIVIDUAL
************************************************************
*********************
HARDWARE LIST
*********************
#1 7-685-647-79 SCREW +BVTP 3X10 TYPE2 IT-3
#2 7-682-548-09 SCREW +B 3X8
#3 7-685-649-79 SCREW +BVTP 3X14 TYPE2 IT-3
#4 7-621-770-87 SCREW +B 2.6X5
#6 7-685-246-19 SCREW +KTP 3X8 TYPE2 SLIT
#7 7-682-547-04 SCREW +B 3X6
#8 7-621-255-45 SCREW +P 2X6
Ref. No. Part No. Description Remark
––––––– ––––––– ––––––––– ––––––
The components identified by mark
! or dotted line with mark ! are criti-
cal for safety.
Replace only with part number speci-
fied.
Ver 1.1 2002.02
