GB
6
A ON/OFF (Power) button
B Shutter button
C ON/OFF (Power) lamp
D Flash
E Microphone
F Self-timer lamp/Smile Shutter
lamp
G Lens
H LCD screen
I (Playback) button
J Control button
Menu on: v/V/b/B/z
Menu off: DISP/ / /
K For shooting: W/T (Zoom)
button
For viewing: (Playback
zoom) button/ (Index) button
L Mode switch
M Hook for wrist strap
N (USB) / A/V OUT jack
O (Delete) button
P Access lamp
Q MENU button
R Tripod receptacle
• Use a tripod with a screw less
than 5.5 mm (7/32 inches) long.
Otherwise, you cannot firmly
secure the camera, and damage to
the camera may occur.
S Speaker
T Battery/memory card cover
U Memory card slot
V Battery insertion slot
Identifying parts
