D-NE20/NE20LS
Pin No. Pin Name I/O Description
100 AVSDA0 – Ground terminal
101 VREFL I Standard voltage terminal (for built in D/A converter L-ch)
102 AOUTL O Built in D/A converter (L-ch) signal output
103 AVDDA0 – Power supply terminal (+2.7V)
104 AVSMO – Ground terminal
105 EXTAL O System clock signal output
106 XTAL I System clock signal input
107 AVDMO – Power supply terminal (+2.7V)
108 VDIOFS256 – Power supply terminal (+2.1V)
109 DAMPCLK O Master clock signal output to headphone amplifier
110 VDIOAMP – Power supply terminal (+2.1V)
111 PWML O Audio (L-ch) signal output to headphone amplifier
112 PWMR O Audio (R-ch) signal output to headphone amplifier
113 VSSAMP – Ground terminal
114 VSS7 – Ground terminal
115 AVDPLL0 – Power supply terminal (+2.7V)
116 AVSPLL0 – Ground terminal
117 VDIOPLL0 – Power supply terminal (+2.7V)
118 VSS8 – Ground terminal
119 AVSPLL1 – Ground terminal
120 AVDPLL1 – Power supply terminal (+2.7V)
121 VDIOPLL1 – Power supply terminal (+2.7V)
122 VSS9 – Ground terminal
123 XIN – Ground terminal
124 VDIO3 – Power supply terminal (+2.1V)
125 MSDIO I Pull up fixed at “H”
126 DVDD2 – Power supply terminal (+1.5V)
127
PF6/DBG6/X_PLUG_DTC
I Line out plug insert detection signal input
128
PF7/DBG7/X_METAL_DTC
I Line out plug insert detection signal input
129 ADDR_SEK0 O not used
130 ADDR_SEK1 O not used
131 PF3/DBG3 I not used
132 PF2/DBG2 I Hold switch input terminal
133 PF1/SSCK/DBG1 O not used
134 PF0/SSIO/DBG0 O not used
135 VDIO4 – Power supply terminal (+2.7V)
136 AVSSAD – Ground terminal
137 AVDSAD – Power supply terminal (+2.1V)
138 IGEN I Pull up fixed at “H”
139 FE(A) O RF focus error signal output from pick-up
140 SE(B) O RF sled error signal output from pick-up
141 TE(F) O RF tracking error signal output from pick-up
142 CE(E) O RF select error signal output from pick-up
143 VC – Ground terminal
144 RFDC(RFDCO) I RF signal input from pick-up
145 VSS11 – Ground terminal
146 ASYI I ASY signal input
147 BIAS I Pull up fixed at “H”
148 ASYO O ASY signal output
