25
D-NE20/NE20LS
Pin No. Pin Name I/O Description
149 AVDASM – Power supply terminal (+2.1V)
150 AVSASM – Ground terminal
151 RFACI I RF signal output from pick-up
152 AVDVCO – Power supply terminal (+2.1V)
153 VCTL I VCT signal input
154 CLTV I Pull up fixed at “H”
155 AVSVCO – Ground terminal
156 VPCO O VPC signal output
157 FILO O FIL signal output
158 FILI I FIL signal input
159 PCO O PC signal output
160 VSS12 – Ground terminal
161 DVDD3 – Power supply terminal (+1.5V)
162 VDIODSP – Power supply terminal (+2.1V)
163 SFDR O Sled servo drive PWM signal output to motor driver
164 SRDR O Sled servo drive control signal output to motor driver
165 TFDR O Tracking servo drive PWM signal output to coil driver (+)
166 TRDR O Tracking servo drive PWM signal output to coil driver (-)
167 FFDR O Focus servo drive PWM signal output to coil driver (+)
168 FRDR O Focus servo drive PWM signal output to coil driver (-)
169 MDP O PWM signal output to motor driver
170 MDS – not used
171 C176 O Data signal output to motor driver
172 VDIOEM0 – Power supply terminal (+2.7V)
173 DVDD4 – Power supply terminal (+1.5V)
174 VSS14 – Ground terminal
175 PC3/XSCS0 O Command latch signal output to power controller
176 PC2/SI0 I Serial data signal input from EEPROM
177 PC1/SO0 O Serial data signal output to power controller/EEPROM
178 PC0/XSCK0 O Clock signal output to power controller/EEPROM
179 VSS15 – Ground terminal
180 VDIO5 – Power supply terminal (+2.1V)
181 PG7 I Reset signal output to power controller
182 PG6 O LED 1 drive control signal output
183 PG5 O LED 2 drive control signal output
184 PG4 O Reset signal output to LCD driver (not used)
185 PG3 O Switching line/headphone signal output (L = headphone)
186 PG2 O LED 3 drive control signal output (not used)
187 PG1 O RF gain control signal output to pick-up
188 PG0 O Standby control signal output to pick-up
189 DVDD5 – Power supply terminal (+1.5V)
190 DVDD6 – Power supply terminal (+1.5V)
191 VSS18 – Ground terminal
192 AVDAD – Power supply terminal (+2.1V)
193 AVSAD – Ground terminal
194 AN7 I Lid upper open/close detection switch input terminal
195 AN6 I Rest of rechargeable battery detection
196 AN5 I Battery voltage detection
197 AN4 I Remote control key signal input
