D-NF430/NF431
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
SECTION 7
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA... : µA... uPA... : µPA...
uPB... : µPB... uPC... : µPC...
uPD... : µPD...
• CAPACITORS
uF: µF
• COILS
uH: µH
X-2108-142-1 MAIN BOARD, COMPLETE (for SERVICE)
(NF430: US)
X-2108-145-1 MAIN BOARD, COMPLETE (for SERVICE)
(NF430: UK)
X-2109-118-1 MAIN BOARD, COMPLETE (for SERVICE)
(NF431)
*********************
2-187-932-11 TERMINAL BOARD (+)
2-187-933-11 SPRING (−), COIL
< CAPACITOR >
C101 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C102 1-164-939-11 CERAMIC CHIP 0.0022uF 10% 50V
C103 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C104 1-162-910-11 CERAMIC CHIP 5PF 0.25PF 50V
C105 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
(NF430: US)
C106 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C107 1-164-882-11 CERAMIC CHIP 220PF 5% 16V
(NF430: US)
C108 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
(NF430: US)
C109 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
(NF430: US)
C110 1-164-866-11 CERAMIC CHIP 47PF 5% 50V
C113 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C114 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C115 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C116 1-126-208-21 ELECT CHIP 47uF 20% 4V
C117 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C118 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C119 1-164-866-11 CERAMIC CHIP 47PF 5% 50V
C120 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C121 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C122 1-135-151-21 TANTALUM CHIP 4.7uF 20% 4V
C123 1-135-151-21 TANTALUM CHIP 4.7uF 20% 4V
C124 1-100-385-11 CERAMIC CHIP 0.47uF 25V
C125 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C126 1-164-935-11 CERAMIC CHIP 470PF 10% 50V
C127 1-164-941-11 CERAMIC CHIP 0.0047uF 10% 16V
C128 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C129 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C130 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C131 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C132 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C133 1-100-506-11 CERAMIC CHIP 1uF 20% 6.3V
C134 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C135 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C136 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C137 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C138 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C139 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C140 1-100-415-11 CERAMIC CHIP 0.47uF 10% 6.3V
C141 1-100-415-11 CERAMIC CHIP 0.47uF 10% 6.3V
C142 1-164-858-11 CERAMIC CHIP 22PF 5% 50V
C143 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V
C144 1-164-845-11 CERAMIC CHIP 5PF 0.25PF 50V
C145 1-135-259-11 TANTALUM CHIP 10uF 20% 6.3V
C146 1-164-506-11 CERAMIC CHIP 4.7uF 16V
C147 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C148 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C149 1-164-842-11 CERAMIC CHIP 2PF 0.25PF 50V
(NF430: US)
C150 1-164-844-11 CERAMIC CHIP 4PF 0.25PF 50V
C155 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C156 1-100-506-11 CERAMIC CHIP 1uF 20% 6.3V
C160 1-218-990-11 SHORT CHIP 0
C162 1-164-845-11 CERAMIC CHIP 5PF 0.25PF 50V
C164 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C201 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C202 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C205 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C206 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C207 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(NF430: US)
C207 1-115-156-11 CERAMIC CHIP 1uF 10V
(NF430: UK/NF431)
C210 1-128-995-21 ELECT CHIP 100uF 20% 10V
C211 1-100-506-11 CERAMIC CHIP 1uF 20% 6.3V
C212 1-100-415-11 CERAMIC CHIP 0.47uF 10% 6.3V
C215 1-100-506-11 CERAMIC CHIP 1uF 20% 6.3V
C216 1-165-887-11 CERAMIC CHIP 0.22uF 10% 6.3V
C217 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V
C218 1-165-887-11 CERAMIC CHIP 0.22uF 10% 6.3V
C219 1-100-735-11 CERAMIC CHIP 10uF 20% 4V
C220 1-100-507-91 CERAMIC CHIP 4.7uF 20% 6.3V
C221 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V
C223 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V
MAIN
The components identified by mark
0 or dotted line with mark 0 are
critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
To Next Page
