Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
C439 1-104-914-11 TANTAL. CHIP 22uF 20% 16V
C440 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C441 1-164-346-11 CERAMIC CHIP 1uF 16V
C442 1-164-346-11 CERAMIC CHIP 1uF 16V
C443 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C444 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C445 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C446 1-104-851-11 TANTAL. CHIP 10uF 20% 10V
C447 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C490 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C491 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C501 1-162-921-11 CERAMIC CHIP 33PF 5% 50V
(T101)
C501 1-162-913-11 CERAMIC CHIP 8PF 0.5PF 50V
(T401, T405)
C502 1-162-920-11 CERAMIC CHIP 27PF 5% 50V
(T401, T405)
C503 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C504 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C505 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C506 1-115-565-11 CERAMIC CHIP 2.2uF 10% 10V
C507 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C509 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C510 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C513 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C514 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C515 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C516 1-126-246-11 ELECT CHIP 220uF 20% 4V
C517 1-110-569-11 TANTAL. CHIP 47uF 20% 6.3V
C518 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C519 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C520 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C521 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C522 1-164-492-11 CERAMIC CHIP 0.15uF 10% 16V
C523 1-115-565-11 CERAMIC CHIP 2.2uF 10% 10V
C524 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C525 1-110-569-11 TANTAL. CHIP 47uF 20% 6.3V
C526 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C527 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C528 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C529 1-110-569-11 TANTAL. CHIP 47uF 20% 6.3V
C530 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C531 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C532 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C534 1-162-921-11 CERAMIC CHIP 33PF 5% 50V
C535 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C536 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C537 1-104-852-11 TANTAL. CHIP 22uF 20% 10V
C538 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C539 1-110-501-11 CERAMIC CHIP 0.33uF 10% 16V
C540 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C541 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C542 1-115-156-11 CERAMIC CHIP 1uF 10V
C543 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C544 1-164-816-11 CERAMIC CHIP 220PF 2% 50V
C545 1-164-816-11 CERAMIC CHIP 220PF 2% 50V
C546 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C547 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C548 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C549 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C550 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C552 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C558 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C559 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C560 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C561 1-107-686-11 TANTAL. CHIP 4.7uF 20% 16V
C562 1-107-686-11 TANTAL. CHIP 4.7uF 20% 16V
C563 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C564 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C565 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C566 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C569 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C604 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
(T401, T405)
C611 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
C613 1-107-686-11 TANTAL. CHIP 4.7uF 20% 16V
(T405)
C801 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C802 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C803 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C804 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C805 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C806 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C807 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C808 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C809 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C811 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C812 1-164-346-11 CERAMIC CHIP 1uF 16V
C815 1-104-851-11 TANTAL. CHIP 10uF 20% 10V
C819 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C820 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C821 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C822 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
< CONNECTOR >
CN501 1-566-530-11 CONNECTOR, FPC (ZIF) 14P
* CN502 1-695-320-21 PIN, CONNECTOR (1.5MM)(SMD) 2P
* CN503 1-695-320-31 PIN, CONNECTOR (1.5MM)(SMD) 2P
* CN504 1-695-320-51 PIN, CONNECTOR (1.5MM)(SMD) 2P
CN601 1-766-295-31 CONNECTOR, BOARD TO BOARD 24P
(T401, T405)
CN801 1-766-492-21 CONNECTOR, FFC/FPC (ZIF) 24P
< DIODE >
D101 8-719-039-99 DIODE UMZ8.2T
D102 8-719-158-15 DIODE RD5.6S-B
D201 8-719-039-99 DIODE UMZ8.2T
D202 8-719-158-15 DIODE RD5.6S-B
D301 8-719-988-78 DIODE SB007W03Q
D302 8-719-988-78 DIODE SB007W03Q
D303 8-719-988-62 DIODE 1SS355
D304 8-719-988-78 DIODE SB007W03Q
D305 8-719-941-09 DIODE DAP202U
D306 8-719-988-62 DIODE 1SS355
D307 8-719-058-24 DIODE RB501V-40TE-17
D308 8-719-058-24 DIODE RB501V-40TE-17
D401 8-719-048-98 DIODE RB160L-40TE25
D402 8-719-048-98 DIODE RB160L-40TE25
D403 8-719-048-98 DIODE RB160L-40TE25
CD
— 21 —
