Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 25 —
< SWITCH >
S301 1-762-078-11 SWITCH, SLIDE (AVLS)
S801 1-570-953-11 SWITCH, PUSH (1 KEY) (OPEN)
S802 1-762-455-21 SWITCH, PUSH (1 KEY) (BATT)
S803 1-762-078-11 SWITCH, SLIDE (RESUME)
S804 1-762-078-11 SWITCH, SLIDE (HOLD)
< TRANSFORMER >
T401 1-429-850-11 TRANSFORMER, DC-DC CONVERTER
T402 1-429-851-11 TRANSFORMER, DC-DC CONVERTER
< VIBRATOR >
X301 1-760-023-21 VIBRATOR, CRYSTAL 16.9MHz
X801 1-579-063-21 VIBRATOR, CERAMIC 4.19MHz
************************************************************
A-3306-394-A ESP BOARD, COMPLETE (T405)
********************
A-3306-405-A ESP BOARD, COMPLETE (T401)
********************
< CAPACITOR >
C601 1-164-346-11 CERAMIC CHIP 1uF 16V
(T401, T405)
C602 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(T401, T405)
C603 1-164-346-11 CERAMIC CHIP 1uF 16V
(T401, T405)
< CONNECTOR >
CN602 1-778-710-41 CONNECTOR, BOARD TO BOARD 24P
(T401, T405)
< IC >
IC601 8-759-445-16 IC SM5859AF (T401)
IC601 8-759-489-29 IC SM5858DF (T405)
IC602 8-759-498-44 IC MSM51V4400D-70TSK (T401, T405)
< JUMPER CHIP >
JC604 1-216-864-11 METAL CHIP 0 5% 1/16W
(T401, T405)
< RESISTOR >
R602 1-216-833-11 METAL CHIP 10K 5% 1/16W
(T401, T405)
R609 1-216-864-11 METAL CHIP 0 5% 1/16W
(T401, T405)
R612 1-216-821-11 METAL CHIP 1K 5% 1/16W
(T405)
R614 1-216-864-11 METAL CHIP 0 5% 1/16W
(T405)
R615 1-216-864-11 METAL CHIP 0 5% 1/16W
(T405)
************************************************************
A-3293-384-A TUNER BOARD, COMPLETE (JEW)
***********************
A-3293-385-A TUNER BOARD, COMPLETE
**********************
(E13, E33, E92, CN, AUS, US, CND, HK)
A-3293-386-A TUNER BOARD, COMPLETE
**********************
(AEP, IT, UK, EA, FR)
1-694-264-11 CONDUCTIVE BOARD, CONNECTION
4-989-982-01 HOLDER (LCD)
< CAPACITOR >
C6 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C7 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C8 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C9 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C10 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C11 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C12 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C13 1-162-911-11 CERAMIC CHIP 6PF 0.5PF 50V
C14 1-162-913-11 CERAMIC CHIP 8PF 0.5PF 50V
C15 1-162-975-11 CERAMIC CHIP 24PF 5% 50V
C16 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C17 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C18 1-162-912-11 CERAMIC CHIP 7PF 0.5PF 50V
(EXCEPT JEW)
C19 1-162-905-11 CERAMIC CHIP 1PF 0.25PF 50V
C20 1-162-928-11 CERAMIC CHIP 120PF 5% 50V
C21 1-162-905-11 CERAMIC CHIP 1PF 0.25PF 50V
C22 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C23 1-104-852-11 TANTAL. CHIP 22uF 20% 10V
C24 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C25 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C26 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C27 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C28 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C29 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C30 1-164-816-11 CERAMIC CHIP 220PF 2% 50V
C31 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C32 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C33 1-104-852-11 TANTAL. CHIP 22uF 20% 10V
C34 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C35 1-162-918-11 CERAMIC CHIP 18PF 5% 50V
C36 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C37 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C38 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C39 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C40 1-104-852-11 TANTAL. CHIP 22uF 20% 10V
C41 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C42 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C43 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C44 1-104-912-11 TANTAL. CHIP 3.3uF 20% 16V
C45 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C46 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C47 1-115-156-11 CERAMIC CHIP 1uF 10V
C48 1-115-156-11 CERAMIC CHIP 1uF 10V
C49 1-104-912-11 TANTAL. CHIP 3.3uF 20% 16V
C50 1-163-139-00 CERAMIC CHIP 820PF 5% 50V
CD ESP TUNER
