Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 28 —
R76 1-216-841-11 METAL CHIP 47K 5% 1/16W
R77 1-216-841-11 METAL CHIP 47K 5% 1/16W
R78 1-216-853-11 METAL CHIP 470K 5% 1/16W
R79 1-216-853-11 METAL CHIP 470K 5% 1/16W
R80 1-216-821-11 METAL CHIP 1K 5% 1/16W
R81 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R82 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R83 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R84 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R85 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
R86 1-216-833-11 METAL CHIP 10K 5% 1/16W
R87 1-216-821-11 METAL CHIP 1K 5% 1/16W
R90 1-216-841-11 METAL CHIP 47K 5% 1/16W
R91 1-216-841-11 METAL CHIP 47K 5% 1/16W
R92 1-216-845-11 METAL CHIP 100K 5% 1/16W
R93 1-216-845-11 METAL CHIP 100K 5% 1/16W
R94 1-216-847-11 METAL CHIP 150K 5% 1/16W
R95 1-216-833-11 METAL CHIP 10K 5% 1/16W
R96 1-216-845-11 METAL CHIP 100K 5% 1/16W
R97 1-216-845-11 METAL CHIP 100K 5% 1/16W
R98 1-216-847-11 METAL CHIP 150K 5% 1/16W
R99 1-216-833-11 METAL CHIP 10K 5% 1/16W
R100 1-216-833-11 METAL CHIP 10K 5% 1/16W
R101 1-216-833-11 METAL CHIP 10K 5% 1/16W
R102 1-216-845-11 METAL CHIP 100K 5% 1/16W
R103 1-216-845-11 METAL CHIP 100K 5% 1/16W
R112 1-216-821-11 METAL CHIP 1K 5% 1/16W
R113 1-216-833-11 METAL CHIP 10K 5% 1/16W
R114 1-216-849-11 METAL CHIP 220K 5% 1/16W
R115 1-218-880-11 RES,CHIP 24K 0.50% 1/16W
< VARIABLE RESISTOR >
RV1 1-223-578-11 RES, ADJ, METAL GLAZE 22K
< SWITCH >
S1 1-771-053-21 SWITCH, KEY BOARD (TUNE+)
S2 1-771-053-21 SWITCH, KEY BOARD (BAND)
S3 1-771-053-21 SWITCH, KEY BOARD (2)
S4 1-771-053-21 SWITCH, KEY BOARD (4)
S5 1-771-053-21 SWITCH, KEY BOARD (TUNE–)
S6 1-771-053-21 SWITCH, KEY BOARD (1)
S7 1-771-053-21 SWITCH, KEY BOARD (3)
S8 1-771-053-21 SWITCH, KEY BOARD (5)
S10 1-572-922-11 SWITCH, SLIDE (FUNCTION)
S11 1-572-922-11 SWITCH, SLIDE (STEP)
(E13, E33, E92, CN, AUS, US, CND, HK, JEW)
S12 1-692-605-11 SWITCH, SLIDE (MEGA BASS)
S21 1-771-053-21 SWITCH, KEY BOARD (PLAY/PAUSE)
S22 1-771-053-21 SWITCH, KEY BOARD (FR)
S23 1-771-053-21 SWITCH, KEY BOARD (FF)
S24 1-771-053-21 SWITCH, KEY BOARD (STOP)
S25 1-771-053-21 SWITCH, KEY BOARD (PLAY MODE)
S26 1-771-053-21 SWITCH, KEY BOARD (REPEAT/ENT)
S28 1-771-053-21 SWITCH, KEY BOARD (ESP)
< TRANSFORMER >
T1 1-416-184-11 COIL, IFT
T2 1-411-603-11 COIL (AM-MIX)
T3 1-431-243-11 TRANSFORMER, DC-DC CONVERTER
T4 1-406-404-11 COIL (MW OSCILATION)
< VIBRATOR >
X1 1-760-423-11 VIBRATOR, CRYSTAL 75kHz
X2 1-579-063-21 VIBRATOR, CERAMIC 4.19MHz
************************************************************
ACCESSORIES & PACKING MATERIALS
*******************************
! 1-467-007-21 ADAPTOR, AC (AC-E455) (AUS)
! 1-467-009-21 ADAPTOR, AC (AC-E455) (US, CND)
! 1-467-012-11 ADAPTOR, AC (AC-E455) (EA)
! 1-467-195-11 ADAPTOR, AC (AC-E455A) (US, CND ,E92)
! 1-467-550-11 ADAPTOR, AC (AC-E455A) (JEW)
! 1-467-550-11 ADAPTOR, AC (AC-E455A) (E33, JEW)
! 1-473-115-11 ADAPTOR, AC (AC-E455D) (UK)
! 1-473-116-31 ADAPTOR, AC (AC-E455D)
(AEP, IT, FR, E13, CN)
! 1-475-623-11 ADAPTOR, AC (AC-E455) (HK)
1-528-444-11 BATTERY PACK (BP-DM10)
(T405: CND, E13, E33, E92, CN, HK, AUS, JEW)
1-528-444-31 BATTERY PACK (BP-DM10) (T405: US)
1-528-444-81 BATTERY PACK (BP-DM10)
(T405: AEP, IT, UK, FR)
1-559-906-32 CORD, CONNECTION
(T101/T401,T405: US, CND, E13, E33, E92, CN, AUS/T405: HK)
! 1-569-007-11 ADAPTOR, CONVERSION 2P (T405: JEW)
! 1-569-007-11 ADAPTOR, CONVERSION 2P (E33, JEW)
! 1-569-008-11 ADAPTOR, CONVERSION 2P (E13, EA, CN)
! 1-569-008-21 ADAPTOR, CONVERSION 2P (E13, EA, CN)
1-751-419-11 CORD, CONNECTIONT
(T101/T401, T405: US, CND, E13, E33, E92, CN, AUS/T405: HK)
1-759-042-21 BATTERY CASE
(T405: AEP, IT, UK, FR, E13, E33, CN, HK, AUS, JEW)
1-769-723-11 CORD, CONNECTION
(T101/T401, T405: US, CND, E13, E33, E92, CN, AUS/T405: HK)
3-860-092-11 MANUAL, INSTRUCTION (SPANISH)
(T101: AEP)
3-860-092-21 MANUAL, INSTRUCTION (ENGLISH)
(T101: AEP, UK, EA)
3-860-092-31 MANUAL, INSTRUCTION (FRENCH) (T101: AEP)
3-860-092-41 MANUAL, INSTRUCTION (DUTCH) (T101: AEP)
3-860-092-51 MANUAL, INSTRUCTION (SWEDISH)
(T101: AEP)
3-860-092-61 MANUAL, INSTRUCTION (PORTUGUESE)
(T101: AEP)
3-860-092-81 MANUAL, INSTRUCTION (ITALIAN) (T101: IT)
3-860-093-11 MANUAL, INSTRUCTION (CHINESE)
(T101: E13, CN)
TUNER
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
To Next Page
