3 Second microphone
4 Proximity/Light sensor
5 Ear speaker/Second speaker
6 Front camera lens
7 Cover for nano SIM and memory card slot
8 Power key
9 Volume/Zoom key
10 Camera key
11 Main microphone/Speaker
12 Main camera lens
13 Camera light
14 GPS antenna area
15 Wi-Fi/Bluetooth antenna area
16 Cover for charger/USB cable port
17 NFC™ detection area
18 Charging dock connector
19 Strap hole
Assembly
Your device only supports nano SIM cards.
