Step 1: Installing the System
Install the system by referring to the illustration below.
To attach the foot pads to the subwoofer
Note
• Use caution when placing the speakers and/or speaker stands attached to the speakers on a specially treated (waxed,
oiled, polished, etc.) floor, as staining or discoloration may result.
(DAV-DZ740 only)
For assembling the speakers refer to the supplied “Speaker Installation Guide.”
Getting Started
How to position the system
Assembling the speakers
AB
DE
F
C
G
A Front speaker (L (left))
B Front speaker (R (right))
C Center speaker
D Surround speaker (L (left))
E Surround speaker (R (right))
F Subwoofer
G Unit
,
Remove the foot pads from
the protective cover.
