Additional Information
93
GB
Rear Panel
A SPEAKER jacks (13)
B SURROUND BACK jack (15)
C VIDEO AUDIO IN (L/R) jacks (19)
D COMPONENT VIDEO OUT jacks (19)
E SAT OPTICAL DIGITAL IN jack (20)
F AM terminals (17)
G FM 75Ω COAXIAL jack (17)
H MONITOR OUT (VIDEO/S VIDEO) jacks
(19)
I SAT AUDIO IN (L/R) jacks (19)
AUDIO IN
VIDEO
SURROUND
BACK
SAT
SAT
SPEAKER
AUDIO IN
OPTICAL
DIGITAL IN
RL
RL
CENTER FRONT LFRONT R
SURR L
WOOFER
WOOFERSURR R
COAXIAL
AM
FM 75
COMPOMEMT VIDEO OUT
MONITOR OUT
S VIDEO
(DVD ONLY)
VIDEO
YP
B
/C
B
P
R
/C
R
