Index to Parts and Control
For more information, refer to the pages indicated in parentheses.
A Disc tray
B Front panel display (page 14)
C (remote sensor)
Receives the remote signal. Point the
remote toward here when using the remote.
D MASTER VOLUME control
Adjusts the system’s volume.
E REC TO USB (page 51)
Transfers tracks/MP3 files/radio programs*
onto a USB device.
* Except for North American models
F (USB) port (page 31)
Used for connecting a USB device or iPod*.
* DAV-TZ210: Australian models only; DAV-
TZ510/DAV-TZ710: North American models
only.
G FUNCTION
Selects the playback source.
H Play operation buttons
Z (open/close)
Opens or closes the disc tray.
N (play)
Starts or re-starts playback.
x (stop)
Stops playback and remembers the stop
point (resume point).
I "/1 (on/standby)
Turns on the unit, or sets it to standby mode.
Front panel
