DCR-DVD91E/DVD101/DVD101E
Ref. No. Part No. Description Ref. No. Part No. Description
5-2. ELECTRICAL PARTS LIST
— 77 —
A-1055-384-A MD-104 BOARD, COMPLETE (SERVICE)
(DVD101/DVD101E)
**************************************
A-1061-612-A MD-104 BOARD, COMPLETE (SERVICE)
(DVD91E)
**************************************
(Since a service is provided only for the MD BLOCK ASSY
(DVD91E:A-7113-373-A, DVD101/DVD101E: A-7113-371-A)
and not for the single MD-104 board, complete)
< CAPACITOR >
C4001 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C4002 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C4003 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C4004 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C4005 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4006 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C4007 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4008 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4009 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C4010 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C4011 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4012 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4013 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4014 1-164-882-11 CERAMIC CHIP 220PF 5% 16V
C4015 1-107-682-11 CERAMIC CHIP 1uF 10% 16V
C4016 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4017 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C4018 1-137-704-91 TANTAL. CHIP 10uF 20% 10V
C4019 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4020 1-164-941-11 CERAMIC CHIP 0.0047uF 10% 16V
C4021 1-117-949-81 CERAMIC CHIP 820PF 10% 50V
C4023 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C4024 1-165-875-11 CERAMIC CHIP 10uF 10% 10V
C4025 1-165-875-11 CERAMIC CHIP 10uF 10% 10V
C4026 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C4027 1-165-875-11 CERAMIC CHIP 10uF 10% 10V
C4028 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C4029 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C4030 1-127-772-81 CERAMIC CHIP 33000PF 10% 10V
C4031 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C4032 1-125-889-91 CERAMIC CHIP 2.2uF 10% 10V
C4033 1-125-889-91 CERAMIC CHIP 2.2uF 10% 10V
C4034 1-125-889-91 CERAMIC CHIP 2.2uF 10% 10V
C4035 1-125-889-91 CERAMIC CHIP 2.2uF 10% 10V
C4036 1-125-889-91 CERAMIC CHIP 2.2uF 10% 10V
C4038 1-125-889-91 CERAMIC CHIP 2.2uF 10% 10V
C4040 1-125-889-91 CERAMIC CHIP 2.2uF 10% 10V
C4041 1-127-820-11 CERAMIC CHIP 4.7uF 10% 16V
C4042 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
C4043 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
C4044 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C4045 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C4046 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C4047 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
C4049 1-165-856-91 CERAMIC CHIP 1uF 10% 25V
C4050 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C4051 1-164-939-11 CERAMIC CHIP 0.0022uF 10% 50V
C4052 1-125-827-91 CERAMIC CHIP 1uF 10% 25V
C4053 1-165-897-11 TANTAL. CHIP 22uF 20% 10V
C4054 1-165-897-11 TANTAL. CHIP 22uF 20% 10V
C4056 1-131-862-91 TANTAL. CHIP 47uF 20% 4V
C4057 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C4058 1-100-352-91 CERAMIC CHIP 1uF 20% 16V
C4059 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C4060 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C4061 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C4062 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C4063 1-127-715-91 CERAMIC CHIP 0.22uF 10% 16V
C4064 1-165-897-11 TANTAL. CHIP 22uF 20% 10V
C4065 1-127-820-11 CERAMIC CHIP 4.7uF 10% 16V
C4066 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C4067 1-164-939-11 CERAMIC CHIP 0.0022uF 10% 50V
C4068 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C4069 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
(-14)
C4069 1-127-895-91 TANTAL. CHIP 22uF 20% 4V (-13)
C4070 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C4071 1-125-889-91 CERAMIC CHIP 2.2uF 10% 10V
C4072 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C4073 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C4074 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
(-14)
C4074 1-119-756-11 TANTAL. CHIP 22uF 20% 6.3V
(-13)
C4075 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C4076 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C4077 1-125-889-91 CERAMIC CHIP 2.2uF 10% 10V
C4078 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C4079 1-119-750-11 TANTAL. CHIP 22uF 20% 6.3V
C4080 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
(-14)
C4080 1-119-756-11 TANTAL. CHIP 22uF 20% 6.3V
(-13)
C4081 1-113-987-11 TANTAL. CHIP 4.7uF 20% 25V
C4082 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C4200 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
(DVD101/DVD101E)
C4201 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
(DVD101/DVD101E)
C4202 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
(DVD101/DVD101E)
C4203 1-117-748-81 CERAMIC CHIP 10PF 0.1PF 16V
(DVD101/DVD101E)
C4204 1-117-748-81 CERAMIC CHIP 10PF 0.1PF 16V
(DVD101/DVD101E)
C4205 1-137-710-11 CERAMIC CHIP 10uF 20% 6.3V
(DVD101/DVD101E)
C4206 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
(DVD101/DVD101E)
C4207 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
(DVD101/DVD101E)
C4208 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
(DVD101/DVD101E)
C4209 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
(DVD101/DVD101E)
MD-104
