Sony DCR-DVD91E - Page 98

DCR-DVD91E/DVD101/DVD101E
— 57 —
board name
MD-104
VC-353
parts location
(shown on page)
71, 72 (Suffix -13),
72, 73 (Suffix -14)
73, 74
number of layers
8
8
layers not shown
2 to 7
2 to 7
pattern
BOARD INFORMATION
(For printed wiring boards)
•
: Uses unleaded solder.
•
: Pattern from the side which enables seeing.
(The other layers’ patterns are not indicated)
• Through hole is omitted.
• Circled numbers refer to waveforms.
• There are a few cases that the part printed on diagram
isn’t mounted in this model.
• C: panel designation
(ENGLISH)
THIS NOTE IS COMMON FOR WIRING BOARDS
(In addition to this, the necessary note is printed in each block)
