4-37E
DCR-HC23E/HC24E/HC26/HC26E/HC35E_L2
no mark : side A
*
mark : side B
4-3. PRINTED WIRING BOARDS
4-3. PRINTED WIRING BOARDS
PD-281, SI-051
PD-281 BOARD
C9603 A-4
C9605 B-4
C9606 C-4
CN9601 A-2
CN9602 B-4
CN9603 B-2
CN9604 A-4
CN9605 C-5
D9602 B-4
* D9603 B-5
* D9604 C-5
* D9605 A-5
Q9601 A-4
Q9602 A-4
R9602 A-3
R9603 A-3
R9604 B-3
R9607 B-4
* BT601 B-2
* C616 D-1
* C617 D-1
CN601 C-1
* CN603 A-1
* CN604 B-1
* CN605 D-2
* D602 D-1
* D603 D-1
D606 B-1
* D608 B-1
F601 B-1
F602 B-1
FB601 D-1
FB602 D-1
* IC601 C-2
* LF602 C-1
* LF603 C-1
* R623 B-2
* R624 B-1
* RB602 B-1
SI-051 BOARD
4-4. MOUNTED PARTS LOCATION
