— 2 —
DCR-HC23E/HC24E/HC26/HC26E/HC35E_L2
3. BLOCK DIAGRAM
! : Points deleted portion.
3-5. OVERALL BLOCK DIAGRAM (5/5)
(Service manual page 3-5)
Former New
FP-381 FLEXIBLE BO
A
CN2001
19 - 2313 - 17
24
1 - 5
ACV_UNREG
ACV_GND
BATT_UNREG
Q2003,
Q2004
BATT/XEXT
Q2001,
Q2002,
Q2006
E
G
E
G
E
G
E
G
E
CT
CRADLE model
FP-381 FLEXIBLE BO
A
CN2001
19 - 2313 - 17
24
1 - 5
ACV_UNREG
ACV_GND
BATT_UNREG
Q2003,
Q2004
LF2001
BATT/XEXT
Q2001,
Q2002,
Q2006
E
G
E
G
E
G
E
G
E
CT
CRADLE model
$
3-6. POWER BLOCK DIAGRAM (1/3)
(Service manual page 3-6)
Former New
CN2001
BATT/XEXT
ACV_UNREG
ACV_GND
BATT UNREG
19 - 2313 - 17
24
FP-381
FLEXIBLE
BOARD
VC-416 BOARD (1/3)
Q2001, Q20
0
Q2006
CRADL
E
CN2001
BATT/XEXT
ACV_UNREG
ACV_GND
BATT UNREG
19 - 2313 - 17
24
LF2001
FP-381
FLEXIBLE
BOARD
VC-416 BOARD (1/3)
Q2001, Q20
0
Q2006
CRADL
E
$

Sony DCR-HC23E Specifications

General

Filter size	25 mm
Digital zoom	640 x
Optical zoom	20 x
Focal length range	2.3 - 46 mm
Sensor type	CCD
Total megapixels	0.8 MP
Optical sensor size	1/6 \
Fader	Black, White, Mosaic, Monotone
I/O ports	Audio Out, i.LINK (DV) Out, S-Video Out, USB, Video Out.
Cable type	Stereo AV, USB
Display diagonal	2.5 \
Display resolution	123200 pixels
Bundled software	Picture Package
Camera shutter speed	1/50 - 1/3500 s
Built-in microphone	Yes
Playback zoom (max)	No x
Minimum illumination	5 lx
Video formats supported	DV
Camcorder tape type	Mini-DV
DV port	-
S-Video in	No

Weight and Dimensions

Depth	113 mm
Width	65 mm
Height	79 mm
Weight	360 g
