4-73
DCR-PC53E/PC55/PC55E
4-3. PRINTED WIRING BOARDS
4-3. PRINTED WIRING BOARDS
4-4. WAVEFORMS
FP-048/PD-239
FP-048 FLEXIBLE BOARD
H
360 mVp-p
1 Q3901 3
PD-239 BOARD
H
0.5 Vp-p
1 IC7501 ql
H
3.0 Vp-p
2 IC7501 w;
H
3.2 Vp-p
3 IC7501 wa
H
4.8 Vp-p
4 IC7501 wf
H
310 mVp-p
7 IC7501 r;
V
2.8 Vp-p
8 IC7501 rs
H
2.8 Vp-p
9 IC7501 rd
H
330 mVp-p
5 IC7501 ek
H
XX Vp-p
6 IC7501 el
Waveforms of the VC-379 board is not shown.
Page from 4-74 is not shown.
