Sony DCR-PC53E - Electrical Parts List

5-12
DCR-PC53E/PC55/PC55E
Ref. No. Part No. Description Ref. No. Part No. Description
5-2. ELECTRICAL PARTS LIST
Not supplied FP-048 FLEXIBLE BOARD
********************
(Since a service is provided only for
the FLEXIBLE BLOCK ASSY, CCD
(PC55:A-1087-297-A,PC53E/PC55E:A-1087-298-A)
and not for the single FP-048 FLEXIBLE BOARD)
< CAPACITOR >
C3901 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V
C3902 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C3903 1-113-987-11 TANTAL. CHIP 4.7uF 20% 25V
< IC >
IC3901 Not supplied ICX440HKZ-13 (CCD IMAGER)
(IC3901 is included in the FLEXIBLE BLOCK ASSY, CCD
(PC55:A-1087-297-A,PC53E/PC55E:A-1087-298-A))
< COIL >
L3901 1-469-528-91 INDUCTOR 100uH
< TRANSISTOR >
Q3901 8-729-117-73 TRANSISTOR 2SC4178-F14
< RESISTOR >
R3901 1-218-959-11 RES-CHIP 3.3K 5% 1/16W
R3902 1-218-990-11 SHORT CHIP 0 (PC55)
R3903 1-218-990-11 SHORT CHIP 0
************************************************************
A-1084-103-A FP-050 FLEXIBLE BOARD, COMPLETE
******************************
< SWITCH >
S301 1-786-643-21 SWITCH, PUSH (1 KEY)(EJECT)
************************************************************
A-1084-104-A FP-051 FLEXIBLEBOARD, COMPLETE
******************************
< DIODE >
D401 6-501-075-01 DIODE SML412BC4T
< RESISTOR >
R401 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R402 1-216-822-11 METAL CHIP 1.2K 5% 1/10W
R403 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
< SWITCH >
S401 1-771-138-82 SWITCH, KEY BOARD (EASY)
S402 1-771-138-82 SWITCH, KEY BOARD (BATT INFO)
S403 1-771-138-82 SWITCH, KEY BOARD (BACKLIGHT)
S404 1-771-138-82 SWITCH, KEY BOARD (BL ON/OFF)
S405 1-771-138-82 SWITCH, KEY BOARD (2ND START/STOP)
************************************************************
A-1084-105-A FP-052 FLEXIBLE BOARD, COMPLETE
******************************
< CONNECTOR >
CN8102 1-817-913-41 MEMORY STICK DUO CONNECTOR
< DIODE >
D001 8-719-066-44 DIODE CL-270HR-C-TS
************************************************************
A-1084-106-A FP-222 FLEXIBLE BOARD, COMPLETE
******************************
< IC >
IC221 6-705-011-01 IC AN48830B-NL
< SWITCH >
S221 1-786-680-21 SWITCH, DETECTION (SMD) (PANEL REVERS)
************************************************************
A-1084-101-A PD-239 BOARD, COMPLETE
**********************
< CAPACITOR >
C7502 1-164-939-11 CERAMIC CHIP 0.0022uF 10% 50V
C7503 1-165-799-11 TANTAL. CHIP 22uF 20% 4V
C7504 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C7505 1-137-700-11 TANTAL. CHIP 10uF 20% 6.3V
C7506 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C7508 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C7509 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C7510 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C7511 1-137-700-11 TANTAL. CHIP 10uF 20% 6.3V
C7512 1-100-507-91 CERAMIC CHIP 4.7uF 20% 6.3V
C7513 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C7515 1-100-743-91 CERAMIC CHIP 2.2uF 20% 16V
C7516 1-100-743-91 CERAMIC CHIP 2.2uF 20% 16V
C7518 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C7519 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
C7520 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C7521 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C7524 1-100-507-91 CERAMIC CHIP 4.7uF 20% 6.3V
C7525 1-100-507-91 CERAMIC CHIP 4.7uF 20% 6.3V
C7527 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C7528 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C7529 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C7530 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
< CONNECTOR >
CN7502 1-794-322-11 CONNECTOR, FFC/FPC (ZIF) 6P
CN7503 1-794-322-11 CONNECTOR, FFC/FPC (ZIF) 6P
CN7504 1-785-905-11 CONNECTOR, FFC/FPC (ZIF) 24P
CN7505 1-794-322-11 CONNECTOR, FFC/FPC (ZIF) 6P
CN7506 1-794-410-11 CONNECTOR, FPC (ZIF) 27P
Be sure to read “Precautions upon replacing CCD imager”
on page 4-3 when changing the CCD imager.
4-4
FP-222 PD-239FP-052FP-051FP-050FP-048
